MAG2120II Micro Intelligent Public Address System

FOB Price

USD $10 - $300 / Bag

100 Bags(Min.Order)

Supply Ability 100 Bag / Bags per Month

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Description

Features

● 8 inputs & 20/40 outputs audio matrix

● 7" color touch screen for friendly use

● Support 4 remote paging stations

● Support remote computer control

● Weekly timer function: 5 programs, each 500 points

● Built-in monitor speaker for monitoring each zone

● 2 AC power outputs for external equipment

Introduction

MAG2120II (MAG2140II) is a powerful intelligent micro pa system center. It is an 8x20 (8x40) audio matrix. It has all the functions of a normal PA project, such as background music playing, programmed audio playing, remote paging, fire alarm, etc.

It supports 8 audio inputs and 20 (40) audio outputs. The audio sources support AUX inputs, USB, Tuner, built-in

memory, etc. The system supports remote paging and remote computer remote control.

Specification

Model	MAG2120II		MAG2140II
Number of control zone	20 zones		40 zones
Display	7-inch color screen
Control mode	Touch screen/ Remote control/ Wireless remote control
Host Built-in Storage Capacity	8G
Input sensitivity	250mV(±25mV)
Output	1V(0dBV)
Built-in audio source	Radio,MP3
MP3	Frequency response	20Hz-20kHz
	SNR	85dB
	Dynamic range	80dB
	Harmonic distortion	0.05%
Radio	AM	Sensitivity		52dBu
		Receiving range		522kHz-1620kHz
		Pass-band		6kHz
		SNR		35dB
	FM	Sensitivity		26dBu
		Receiving range		87.0MHz-108.0MHz
		Pass-band		15kHz
		SNR		75dB
Wireless control	12 groups,withcontrol distance within 100-1000m
Frequency response	20Hz-20kHz(±3dB) (Single zone)
SNR	85dB
Crosstalk	70dB
Alarm trigger mode	Low level of0V, and high level of5V～24V
Timing power output	PWR1		AC220V/50Hz/500W
	PWR2		AC220V/50Hz/500W
Fuse	Machine protection		F1AL
	Power protection		F10AL
Power supply	AC220V (±10%)/ 50Hz
Overall power consumption	22W
Package dimension (mm)	（L×W×H）555×460×235
Machine dimension (mm)	（L×W×H）484×360×132
Gross weight	11.8kg		12.3kg
Net weight	9.2kg		9.6kg

Connection

Guangzhou DSPPA Audio Co., Ltd. is a professional sound system manufacturers since1988. With more than 30 years' history of designing and manufacturing audio products, DSPPA has enjoyed a high reputation in and out of China.
