Help CenterSell 1000mm Tube Extractor With Diesel Engine Power for Secant Pile Foundation Work
Related Products
-
510mm Diameter Displacement Auger*3000mm Used Fdp Full Displacement PileUS$ 1000 - 3000MOQ: 1 Piece -
Double Wall Casing ID540*620MM USED FOR PILE FOUNDATION WORKUS$ 1000 - 30000MOQ: 1 Piece
-
Casing Joints Male Part and Female Part 1200mm Used for Double Wall CasingUS$ 1000 - 3000MOQ: 1 Piece
-
1000mm Double Wall Casing Joints Male and Female PartUS$ 1000 - 3000MOQ: 1 Piece
-
1200mm Single Wall Casing Joints Male and Female PartUS$ 1000 - 3000MOQ: 1 Piece
casing extractor 600mm with diesel engine power for pile foundation work
They are hydraulic clamping machines to pull out casing pile pipe or similar pipe. Pull out casing pile pipe or similar pipe. They may be coupled to the base pile machine by means of telescopic boom or they can work alone with its own hydraulic power pack
diaphragm wall stop-end extractor
Hydraulic equipment designed for the extraction of diaphragm wall stop-end sheet piles width 600 to 1200 mm The unit is operated by a power pack and it is composed of heavy duty base frame with two trapezoid sliding columns maneuvered by 4 hydraulic rams with 750 mm stroke. The system is complete with locking system pins to ensure the stop end sheet piles to the sliding frames and to prevent dropping of the column.
1drawing tianjin huachang xingye technology co ltd email info@tjdrilling.com whatsapp 008618902059907
name |
unit |
parameter |
remark |
Lift cylinder quantity |
pc |
4 |
|
Max stroke of cylinder |
mm |
800 |
|
Clamp cylinder quantity |
pc |
1 |
|
Max clamp force |
t |
120 |
30MPa |
Max casing diameter |
mm |
1062 |
|
Max lift force |
t |
240 |
30MPa |
Weight |
kg |
4200 |
|
Oversize (L×W×H) |
m |
2.85x1.7x1.6 |
Transport size |
MOTOR POWER STATION |
||
|
MOTOR
|
TRIPLE-PHASE ASYNCHRONOUS MOTOR
|
|
power |
kw |
45 |
speed |
rpm |
1500 |
|
FUEL SUPPLY
|
L/MIN |
100 |
Working pressure |
bar |
300 |
oversize |
mm |
1850*1350*1150 |
weight |
kg |
1200 |
