HZ-20 Gasoline Engine Big Mutha Asphalt And Concrete Pavement Drilling Core Machine

HZ-20 Gasoline Engine Big Mutha Asphalt And Concrete Pavement Drilling Core Machine photo-1
HZ-20 Gasoline Engine Big Mutha Asphalt And Concrete Pavement Drilling Core Machine photo-2
HZ-20 Gasoline Engine Big Mutha Asphalt And Concrete Pavement Drilling Core Machine photo-3
HZ-20 Gasoline Engine Big Mutha Asphalt And Concrete Pavement Drilling Core Machine photo-4
HZ-20 Gasoline Engine Big Mutha Asphalt And Concrete Pavement Drilling Core Machine photo-5
Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Distributor/Wholesaler
Year Established:
2013
Annual Export Value:
US$1 Million - US$1.5 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.



Product Description



HZ-20 Gasoline Engine Big Mutha Asphalt And Concrete Pavement Drilling Core Machine

Characteristics:

1.Suitable to cut/drill cores of concrete, rocks, stones, tiles or the similar materials.

2.The machine is suitable for core samples of size upto 200mm diameter.

 3.The machine has sturdy base with pillar support in which rack and pinion is provided for adjustment in height and penetration assembly.

4.A suitable diesel engine is fitted in the machine with cooling arrangement with water.

5. It has multi-function such as core drilling, cutting and drilling the concrete samples.

It is applicable for core drilling test for concrete and asphalt road surface at roads.
Technical parameters:

1.Maximum diameter of core drilling:200mm

2.Maximum depth of core drilling: 400mm-700mm

3. Main shaft's speed: 200-1000RPM

4. Max. cutting (grinding) diameter: Φ200mm

5.Power of motor: 5.5 HP,HP,13HP

6.Weight:     5.5HP: 160kg   1080×780×1150mm;

                    9 HP    180kg  1080×780×1150mm;

                    13HP   200kg 1200×800×1300mm.

7.About the Muzzle Drill specifications:

  Dia.50mm   standard length:400mm
  Dia.100mm standard length:400mm
  Dia.150mm standard length:400mm
  Dia.200mm standard length:400mm

  Also we can  customize accroding your demand.

Detailed Images





HZ-20 Gasoline Engine Big Mutha Asphalt And Concrete Pavement Drilling Core MachineHZ-20 Gasoline Engine Big Mutha Asphalt And Concrete Pavement Drilling Core Machine

HZ-20 Gasoline Engine Big Mutha Asphalt And Concrete Pavement Drilling Core MachineHZ-20 Gasoline Engine Big Mutha Asphalt And Concrete Pavement Drilling Core MachineHZ-20 Gasoline Engine Big Mutha Asphalt And Concrete Pavement Drilling Core MachineHZ-20 Gasoline Engine Big Mutha Asphalt And Concrete Pavement Drilling Core Machine

FAQ

  HZ-20 Gasoline Engine Big Mutha Asphalt And Concrete Pavement Drilling Core MachineFrequently Asked Question:

1.Are you trade company or factory?

We are trade company but we also have own factories. Building trade company is just for exporting various types of concrete mould and others products.

2. Why your price is higher than others?

As we persist on that each factory should put quality at the first place. We spend time and money on developing how to make machines much more automatic, accurate and high quality. We can make sure that our machine could use more than ten years without any problem. We can provide one years free quality assurance.

3. How to visit your company?

A) Fly to Beijing airport: By high speed train From Beijing Nan to Cangzhou Xi (1 hour),then we can pick up you.

B) Fly to Shanghai Airport: By high speed train From Shanghai Hongqiao to Cangzhou Xi(4.5 hours), then we can pick you up.

Our Services

HZ-20 Gasoline Engine Big Mutha Asphalt And Concrete Pavement Drilling Core Machine1. Installation and training:

a. If buyers visit our factory and check the machine, we will teach you how to installand use the machine, and also train your workers/technician face to face.

b.Without visiting, we will send you user manual and video to teach you to install and operate.

c.If buyer needs our technician to go to your local factory, please arrange board and lodging and other necessary things.

2. After Service:

a.One year guarantee for whole machine.

b.24 hours technical support by email or calling

c.If there is any problem found of the machine, we will repair it for free in one year.

Company Information

 HZ-20 Gasoline Engine Big Mutha Asphalt And Concrete Pavement Drilling Core Machine Oubeiruike supply verious type of products,Test Molds, Concrete Mixer,Asphalt Tester,and Soil Road Lab Tester .... We assure high quality to you.

Packaging & Shipping

 HZ-20 Gasoline Engine Big Mutha Asphalt And Concrete Pavement Drilling Core Machine We can deliver by sea at any port in china, and Also can ship by air via express company (door to door),it is quick and safe.
