China Supplier Cheap Price Used Cooking Oil Purifier Machine/deep Frying Oil Recycling Purifier/using Stainless Steel Filters
China Supplier cheap price used cooking oil purifier machine/deep frying oil recycling purifier/using stainless steel filters
Product Application
1.It dewater, deodorize, and eliminate impurities highly effective.
2.According to cooking oil`s nature of high water, more acid matter, much impurity and offensive
odor content, this machine adopts Plate Pressure system which can separate the sundry goods and
water from the oil quickly and effectively. Then superadd two primary filters and fine filter, it can remove
impurities thoroughly. Next, the machine adopts highly vacuum system to dewater and deodorize. In addition,
this machine uses stainless steel filter element, it resists the acid in oil strongly.


used cooking oil purifier
Parameters | Unit | COP-10 | COP-20 | COP-30 | COP-50 | COP-100 | COP-150 | COP-200 | COP-300 | |||||||
Flow Rate | L/min | 10 | 20 | 30 | 50 | 100 | 150 | 200 | 300 | |||||||
Working Vacuum | MPa | -0.06 ~ -0.095 | ||||||||||||||
Working Pressure | MPa | ≤0.4 | ||||||||||||||
Temperature Range | ℃ | 0 ~ 100 | ||||||||||||||
Power supply | 380V,50Hz, 3 phase (or as customized) | |||||||||||||||
Working noise | dB(A) | ≤75 | ≤75 | ≤75 | ≤78 | ≤78 | ≤78 | ≤80 | ≤82 | |||||||
Heating power | KW | 36 | 40 | 45 | 72 | 80 | 90 | 120 | 135 | |||||||
Total power | KW | 38 | 42 | 47 | 75 | 87 | 101 | 135 | 147 | |||||||
Inlet/outlet | mm | 25 | 25 | 25 | 32 | 42 | 50 | 50 | 60 | |||||||
Net weight | Kg | 450 | 550 | 600 | 750 | 850 | 1000 | 1200 | 1500 | |||||||
Overall dimensions | mm | 1500×1000×1200 | 1500×1050×1600 | 1500×1050×1650 | 1600×1150×1700 | 1750×1250×1800 | 1900×1600×1950 | 1900×1700×2000 | 2100×1700×2100 | |||||||
Product Features
1.The product is equipped with three stage purification, portable, easy to operate, very low price,
no need of purification paper, no contamination to the ground.
2.This machine can fast degas, dewater, and remove the impurities such as the harmful substances,
pigment, suspended solids, FFA and so on.
3.It can enhance the oil quality, restore the cooking oil viscosity, improve the oil`s color and transparence
with the REGENERATION systems, which can reduce acid value, peroxide value, color, odor and
heavy metals augments of frying oil and improve its operational performance
Chongqing TOP is a professional leading manufacturer and supplier of oil purifiers and various related testers. We consists of departments respectively for technological development, machinery manufacture, instrument manufacture, quality control etc. On basis of mature development and manufacture technology and highly qualified production management team, the products own high quality, easy operation, excellent performance and lone service life.
we are able to greatly extend oil and component life, which will significantly reduce maintenance and down time costs.we are proud to offer our products and services to assist our clients in achieving optimal machine performance.
TOP Oil Purifiers uses single or multi-stage filtration to remove, particulate, free water, and small quantities of dissolved water if necessary. The systems are usually customized to suite the specific customer application. Oil "regeneration", "reclamation", "recycling" are all terms used to describe the process of restoring used, aged, contaminated oils to "like new" reusable condition. The reclamation process removes free water, most dissolved water, dissolved gas, particulate, carbon contamination, acids, oxidation by products, most color bodies, wear metals, and most additive chemicals.
TOP Oil Testers works on the development, production, market, technical and after-sale service for petrochemical analyzers, transformer substation electrical testing equipment and circuit detecting equipment. Main products are water content testers, surface/interfacial tension testers, flash point testers, kinematic viscosity testers, oil acidity testers, insulation oil dielectric strength testers, transformer characteristics testers, relay protection testers, high voltage testing equipment etc.
Honest Team - TOP always honestly treat you and keep faith to make you satisfied with every cooperation with us.
Sincere Communication - TOP sincerely communicate with you to guarantee the provided products to be your ideal ones.
Reliable Quality -TOP own high quality and performance for every TOP product is under strict quality control and testing.
Service Commitment - TOP bring you prompt, considerate and professional aftersale service and technical support, and explore technology future together.
SGS and CE Certificates
