Product Description
Hongjin Products Description
50kN 100kN 200kN 300kN material testing laboratory equipments Mechanical Tensile Strength Testing equipment
Universal tensile tester is suitable to test tensile stress, compressive stress, shearing force, peeling force, and elongation of materials, components, and finished products. It is widely used in controling material quality.
Extrude, compression, bending, shearing, stripping, tearing, two-point extension (with additional extensometer) and so on.
| Frame capacity | 100kg-5T |
| Load accuracy | 0.5% F.S |
| Effective force measurement range | 0.4%~100%(0.5 class) |
| Force measurement precision | Within±0.5% |
| Motor | Imported servo motor w/AC variable speed drive system, high-precision mechanical ball screw rod |
| Force reading | kgf, Ibf, N, KN, T etc |
| Effective test width | 400mm(can be widened according to customer requirements) |
| Effective stretch space | 800mm(can be higher by customer requirements) |
| Test speed | 0.1~300mm/min (adjustable) |
| Test speed range | 0.01~500mm/min |
| Safety features | E-Stop Over-load protection Upper and lower limit switches Load sensor with automatic retreat |
| Overload protection | More than 10% of the maximum load, automatic machine protection |
| Fixture configuration | A set of tensile fixture ,Shearing Accessories |
| Vertical test space | 1100mm including fixture |
| Power supply | 220V/50HZ, |
| Power | 0.75KW(according to the different force demand, standard different power motors) |
| Data display | Max. force, speed, sample information, strength(Kpa, Mpa, N/mm, N/mm2) etc… |
1. Tested sample: laminated materials, wood, leather, rubber & plastic, metal material, etc.
2. Different test with different grips: tensile, peel, tear, heat seal, adhesive, bend and open force.
3. Deformation under defined load: Test deformation under defined load of tested sample
4. Load under defined deformation: Test load under defined deformation of tested sample
5. Software can issue word/excel report with results for max. force, elongation, tensile strength, peel strength, tear strength, compression strength, etc.
Hongjin company introduction:
Factory management
Modern equipment and first-class process production, including laser cutting panel and wood, ERP system, production control system, cutting automation, skilled sheet metal department. The assembly workers with more than ten years of experience, the products are updated every year, making the equipment more in line with the testing standards. Our advanced equipment can help us reduce waste
Senior original design team
Research and production base, more than 10 high-tech products, more than 30 product patents
Sales team management
Through professional and rigorous screening and training,
A sales team with a solid professional foundation and 24-hour response.
Superb technology, quality control of inspection agencies, factory direct sales
Focus on product quality, independent quality inspection department strictly inspects each inspection process, and pay attention to customer service, creative design and post-processing production, product quality and quantity, packaging and shipment, we complete each process with quality and quantity .
1. Are your company a trading one or a factory?
Factory ,13years focusing on test instruments field,3 years exporting experience.Our factory is in Dongguan, Guangdong, China
2. Do you offer after-sales service? How can I ask for that? And how about the warranty?
Every machine from our factory has a 12-month warranty after shipment. Generally,
we offer 12 months for the FREE maintenance, while considering of sea transportation,
If your machine doesn’t work, you can send E-mail to us and we will try our best to find
the problem by email or skype video chat if neccesary. After confirmation of the problem,
we can send you new spare parts or provide on-site repair.
3. What’s the delivery term?
At most of time, we have stock in the factory. If there is no stock, normally, the delivery
time is 7-20 working days after deposit receipt. If you are in urgent need, we can consider
making a special arrangement for you.
4. Do you accept customization service? Can I have my logo on the machine?
Yes, of course. We can not only offer standard machines, but also customized
machines according to your requirements. And we can also put your logo on the machine.
5. Do you have a branch company or service office in my country?
We have offices in the belowing:
Hangzhou Branch:
Address: Building 1, Haixiang Industrial Park, No. 1413 Moqianshan Road, Xiangfu Town, Gongshu District, Hangzhou, Zhejiang, China
6. How to install and use the product?
We will send you operating instructions, English video by Email. Or you can download on our
officail website directly.
Most of our machine is shipped with a whole part, which means it is already installed, all you
need to do is to connect the power cable and start to use. And if possible, we can also install
your machine at site.
7. What about the services and product' quality?
Service: ,Design service,Buyer lable service.
Quality: Each instruments must be carried out 100% quality examination and test, the finished products must through a third party
calibration institutions before shipping and delivery goods.
