Help CenterHorizontal Video Measuring Machine For Cutting Tool Drill Measure
Related Products
-
Low Cost Manual Vision Measuring MachineNegotiableMOQ: 1 -
E300 Low Cost Manual Video Measuring MachineNegotiableMOQ: 1
-
Metal Workpiece 3D Automatic Vision Measuring Machine VMMNegotiableMOQ: 1
-
2.5D AutoVision Automatic Video Measuring SystemNegotiableMOQ: 1
-
Hot Selling 3D Metal Workpiece Automatic Video Measuring MachineNegotiableMOQ: 1
Features
1) "HIWIN" P level linear guideway and precision cross roller guideway for increased accuracy & working life Supplied with SBK-E multifunctional 2.5D measuring software, automatic edge detection and vision height measurement function.
2) Supplied with removable & dismountable console support table.
3) High-definition detent step zoom lens and high-resolution CCD performs high-definition measurement.
4) Supports different file formats of data output such as Word, Excel, CAD etc. DXF import for quick inspection.
Specifiaction
W-SERIES HORIZONTAL VIDEO MEASURING MACHINE SPECIFICATIONS |
||||
Model |
W200 |
W300 |
||
Measuring range(mm) |
200*100*200 |
300*200*200 |
||
Machine size(mm) |
950*845*1285 |
1050*845*1285 |
||
Weight(kg) |
150 |
190 |
||
Max. load(kg) |
20 |
20 |
||
Accuracy of X-Y axis |
3+L/200µm |
|||
Accuracy of Z axis |
5+L/200µm |
|||
XYZ resolution |
1.0μm( optional 0.5um or 0.1um scale) |
|||
Repeatability(mm) |
0.003 |
|||
Magnification |
Optics zoom ratio: 0.7-4.5X; image zoom ratio: 24-158X |
|||
Control system |
SBK3000 control box, USB port, adjustable light |
|||
Operated mode |
Handle wheel |
|||
Software Interface
As the branch of SUNPOC group, SOBEKK Precison Instrument is a professional manufacturer for video measuring machine from China with more than 15 years experience, we are made up of 1 factory, 6 after sales service centers, 1R&R center and 1 foreign sales department. we meet the standard of ISO9001,products with CE certificate. now we are service the customers from more than 30 countries and regions . such as :USA, Poland, Hungary, Korea, Vietnam, Thailand, Malaysia ...
Company Goal: to be the most stable supplier for video measuring machine in China
