Help Center16 Beam 3D LIDAR
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Other
Year Established:
2004
Annual Export Value:
US$10 Million - US$50 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
LiDAR-16, is the first of its kind in China, world leading 16-beam miniature LiDAR product.
Its main applications are in autonomous driving, robots environment perception and UAV mapping.
The compact housing of LiDAR-16 mounted with 16 laser/detector pairs rapidly spins and sends out high-frequency laser beams to continuously scan the Surrounding environment. Advanced digital signal processing and ranging algorithms calculate point cloud data and reflectivity of objects to enable machine to 'see' the world and providing reliable data for localization, navigation and obstacle avoidance.
- Laser beam: 16 beams
- Wavelength: 905nm
- Laser class: class1
- Accuracy: ±2cm(typical)
- Range: 20cm to 150m(20% object reflectivity)
- Data rate: 320,000pts/s
- Field of view (vertical): +15.0° to -15.0° (30°)
- Angular resolution(vertical): 2.0º
- Field of view (horizontal): 360º
- Angular resolution (horizontal/azimuth): 0.09º to 0.36º (5-20Hz)
- RPM: 300rpm to 1200rpm(5Hz to 20Hz)
- Input voltage: 9-32VDC
- Power comsumption: 9w(typical)
- Sensor protection: IP67
- Operation temperature: -10°C to +60°C
- Dimension: H:82.7mm*φ:109mm
- Weight: 0.84Kg(without cabling)
- Data type: spatial coordinates/intensity
