Products Description
TPF Cooking oil purifier mainly used to process some vegetable cooking oils, such as rapeseed oil, peanut oil, soybean oil and other vegetable oils, as well as some old fried edible oils. In the crude oil that comes out after pressing, the edible oil contains plant residues, moisture, etc. The TPF vacuum cooking oil purifier can effectively remove residues, moisture, etc. from the oil. This machine uses vacuum negative pressure dehydration, and the process temperature is lower than 60 centigrade degrees, with high-speed dehydration function, The original beneficial components in vegetable oil will not be destroyed during the filtering process, and the original clear fragrance of vegetable oil will not be destroyed. TPF Cooking oil purifier is especially suitable for the fine treatment of vegetable oil. The whole machine is made of food-grade stainless steel 316. The equipment is widely used in vegetable oil processing enterprises.
Features
◆ Vacuum negative dehydration, never destroy the vegetable oil beneficial components
◆ High-efficiency vacuum dehydration and degassing: Duplex-Stereo film evaporation technology
◆ Excellent heating system: carbon fiber electric heater with long service life, low heating surface load, linear temperature
rise, preventing oil cracking, keeping oil uniform heating.
◆ Automatic control to realize unattended, safe and stable working.
◆ Safety interlock protection: oil pump, vacuum pump, heater interlock protection
◆ Humanized instructions: automatic design, and there are instructions such as oil temperature gauge, pressure gauge, vacuum gauge filter pollution alarm, operating status and so on.
◆ Good comprehensive performance: This machine has the advantages of low noise, easy operation, long maintenance interval, low energy consumption, low operating cost, high oil filtration efficiency, long lifetime, etc.
◆ High-efficiency vacuum dehydration and degassing: Duplex-Stereo film evaporation technology
◆ Excellent heating system: carbon fiber electric heater with long service life, low heating surface load, linear temperature
rise, preventing oil cracking, keeping oil uniform heating.
◆ Automatic control to realize unattended, safe and stable working.
◆ Safety interlock protection: oil pump, vacuum pump, heater interlock protection
◆ Humanized instructions: automatic design, and there are instructions such as oil temperature gauge, pressure gauge, vacuum gauge filter pollution alarm, operating status and so on.
◆ Good comprehensive performance: This machine has the advantages of low noise, easy operation, long maintenance interval, low energy consumption, low operating cost, high oil filtration efficiency, long lifetime, etc.
Product Paramenters
Index | Unit | TPF -10 | TPF -30 | TPF -50 | TPF -100 | |||
Flow rate | L/H | 600 | 1800 | 3000 | 6000 | |||
Working Vacuum | Mpa | -0.06 ～ - 0.095 | ||||||
Working Pressure | Mpa | ≤0.4 | ||||||
Working Temperature | ℃ | 0~80 | ||||||
Cleanness | NAS | 6 | ||||||
Impurity Size | μm | 1 | ||||||
Gas Content | % | 0.1 | ||||||
Water content | PPM | ≤ 50 | ||||||
Working noise | dB(A) | ≤75 | ||||||
Heating power | KW | 24 | 24 | 30 | 48 | |||
Total Power | KW | 27 | 27 | 34 | 53 | |||
Inlet / Outlet | mm | 25 | 25 | 32 | 40 | |||
Weight | Kgs | 550 | 600 | 700 | 800 | |||
L | mm | 1500 | 1500 | 1600 | 1700 | |||
W | mm | 1150 | 1150 | 1250 | 1450 | |||
H | mm | 1750 | 1750 | 1800 | 1850 | |||
Pictures Shows
