Low Noise Ultra-High Voltage Transformer Oil Refinery Machine / Oil Filtration Dehydration Plant
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Buying Office
Year Established:
1993
Annual Export Value:
US$5 Million - US$10 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
6000-12000 L/H ZJA Ultra-High Voltage Transformer Oil Recycling Plant / Oil Purifier/Oil Filter MachineNegotiableMOQ: 1 -
Dielectric Oil Purifier and Dielectric Oil Filtration MachineNegotiableMOQ: 1
-
Mobile Type Transformer Oil Filtration MachineNegotiableMOQ: 1
-
High Effective Vacuum Transformer Oil Filtration MachineNegotiableMOQ: 1
-
High Quality Trailer-Type Transformer Oil Regeneration PlantNegotiableMOQ: 1
Products Description
ZJA series UHV oil purifier is mainly used in 220KV / 330KV / 500KV / 750KV / 1000KV ultra-high voltage and UHV grid transmission and transformation projects. Due to the high safety characteristics of ulatra-high voltage and ultra-high voltage power grids, the insulation oil in transformers, transformers and reactors is extremely demanding. ZJA series oil purifier has super strong dehydration, impurity-removal and harmful gas removal capabilities, and has high safety and stable operation capabilities. The equipment is equipped with first-class vacuum pump system, oil transfer system and filtration system. The filter element with high beta value imported filter material has strong oil particle purification ability. The cleanliness of the filtered oil product is above NAS1638-3, the water content is lower than 3PPM, the gas content is lower than 0.01% (methane and hydrogen Harmful gases such as acetylene are zero), and the breakdown voltage of oil products is greater than 75KV, all oil index fully meet the international UHV requirements. This machine also has the functions of vacuum drying, vacuum oil injection, and hot oil circulation. It can also be used as a separate vacuum pumping unit to the transformer and power equipment.
Product Paramenters
Features
◆ The vacuum system uses the roots pump as the main pump and the rotary vane vacuum pump as the primary pump. Fast start-up, large pumping speed, stable performance, and high ultimate vacuum of less than 5Pa.
◆ Double horizontal vacuum separators, combined with Duplex-Stereo film evaporation technology
◆ Strong ability to remove impurities: ultra-large area cylindrical precision filter element, with high filtration accuracy, easy installation and replacement.
◆ Low-load heating: Adopt advanced internal and external double-tube heat radiation indirect heating technology.
◆ Automatic control to realize unattended, safe and stable working.
◆ Safety interlock protection for oil pump, vacuum pump, heater to keep safely working
◆ Low noise, easy operation, long maintenance interval, low energy consumption, low operating cost
◆ It can be used together with the insulation oil regeneration device, which has the effect of decoloring, deacidification, deoxidation and removing free carbon and other harmful substances from the oil.
Company Profile
CHONGQING NAKIN ELECTROMECHANICAL CO.LTD. is a professional mechanism manufacturer (oil purifier) from Chongqing China.The company has a 3000 square meter production workshop with more than 40 staffs and engineers. The company is joint-stock high-tech enterprise, after ten years of development, company has grown into a comprehensive enterprise, engaging in vacuum oil purifier producing, filter element producing, and Imp&Exp trading. NAKIN oil purifier and filter are widely applied in projects of transformer substation, electric department, steel structure, bridge, auto, railway, aviation, chemicals, petroleum etc. The products are exported to more than 30 countries and areas, such as Europe, America, Middle East, Southeast Asia and so on. The product gets the good reputation from the dealer and end user.
