Home > Products > Timer > DIN Rail SUL180 Time Switch Mechanical Timer Switch 24 Hours Programmable Timer 16A Time Switch
DIN Rail SUL180 Time Switch Mechanical Timer Switch 24 Hours Programmable Timer 16A Time Switch
Negotiable
1 (Min.Order)
- 1000 per Month
- T/T Credit Card
You May Like
-
SUL181h SUL181d Mechanical Timer 24 hours Time Switch Relay Electrical Programmable Timer 24 hour Din Rail Timer Switch
-
24 Hour Mechanical Timer Switch EU standard Socket Mechanical Timer 220V 16A EU plug Electrical Program Timer Power Switch
-
24 Hour Mechanical Timer Switch EU standard Socket Mechanical Timer 110V 125V 15A US plug Electrical Program Timer Power Switch
-
24 Hour Programmable Timer Switch Universal Socket Mechanical Timer 220V 16A Europe Plug EU plug EU socket
-
Electric Bell 220V Factory School Ring Time Bell Recess Ring Automatic Bell 6 8 10 12 inch
-
UK Plug Countdown Timer Switch Smart Control Plug In Socket Auto Shut Off Outlet Automatic Turn Off Electronic Device
Product Description
Parameters
Specifications:
working principle:
1. Set the time of the machine/product in advance, mechanically driven;
2. The battery inside the machine can work continuously for 80-100 hours under power failure;
3, the product is a 24-hour time switch, the minimum time set is 15 minutes;
4. The clock icon on the machine faceplate indicates the start of the set time mode;
5. The I graphic on the machine panel indicates the lock setting.
1. Set the time of the machine/product in advance, mechanically driven;
2. The battery inside the machine can work continuously for 80-100 hours under power failure;
3, the product is a 24-hour time switch, the minimum time set is 15 minutes;
4. The clock icon on the machine faceplate indicates the start of the set time mode;
5. The I graphic on the machine panel indicates the lock setting.
Technical Data
| Type | SUL180 |
| Time range | 24 hours |
| Contact capacity | 16A, 220V AC |
| Coil voltage | AC 110V-240V |
| Electrical life | 100, 000 times |
| Mechanical life | 10, 000, 000 times |
| Working reserve time | 70 hours |
| Minimum setting unit | 15 minutes |
| Set-up times | 96 times |
| Operating temperature | -40 - +50° C |
DIN rail mounting
Package content : 1 X SUL180 timer
Product display
