Home > Instruments & Meters > Timer & Counter > SUL180 15 Minutes Mechanical Timer 24 Hours Programmable Din Rail Timer Time Switch Relay Measurement Analysis Instruments
SUL180 15 Minutes Mechanical Timer 24 Hours Programmable Din Rail Timer Time Switch Relay Measurement Analysis Instruments
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Agent
Year Established:
2009
Annual Export Value:
Below US$1 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Digital Temperature Humidity Controller Regulator Thermostat Hygrostat Thermometer Hygrometer Control With Humidity Sensors 220VNegotiableMOQ: 1 -
Dual Digital Thermostat Temperature Humidity Control STC-3028 Thermometer Hygrometer Controller AC 110V 220V DC 12V 24V 10ANegotiableMOQ: 1
-
STC-3008 Dual Digital Thermostat Temperature Controller Incubator Two Relay Output Thermoregulator Heater Cooler 12V 24V 220VNegotiableMOQ: 1
-
KG316S High Load 30A 220V 7 Days Weekly Digital Electronic Lighting Timer Interval 1 Second Power Direct OutputNegotiableMOQ: 1
-
Digital Dual Display Temperature Controller Intelligent Thermostat Regulator Temp Incubator Controller Switch With Dual SensorNegotiableMOQ: 1
parameters
| name | SUL180 Din Rail Time Switch |
1. Set the time of the machine/product in advance, mechanically driven;
2. The battery inside the machine can work continuously for 80-100 hours under power failure;
3, the product is a 24-hour time switch, the minimum time set is 15 minutes;
4. The clock icon on the machine faceplate indicates the start of the set time mode;
5. The I graphic on the machine panel indicates the lock setting.
2. The battery inside the machine can work continuously for 80-100 hours under power failure;
3, the product is a 24-hour time switch, the minimum time set is 15 minutes;
4. The clock icon on the machine faceplate indicates the start of the set time mode;
5. The I graphic on the machine panel indicates the lock setting.
Technical Data
1) Type: SUL180
2) Time range: 24 hours
3) Contact capacity: 16A, 220V AC
4) Coil voltage: AC 110V-240V
5) Electrical life: 100, 000 times
6) Mechanical life: 10, 000, 000 times
7) Working reserve time: 70 hours
8) Minimum setting unit: 15 minutes
9) Set-up times: 96 times
10) Operating temperature: -40 - +50° C
11) DIN rail mounting
