Home > Instruments & Meters > Meter for Liquid & Gas > Thermometer & Hygrometer > RKC CH502 M*AN-NN Short Case Thermostat Digital Display Temperature Control Instrument PID Intelligent Temperature Control
RKC CH502 M*AN-NN Short Case Thermostat Digital Display Temperature Control Instrument PID Intelligent Temperature Control
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Agent
Year Established:
2009
Annual Export Value:
Below US$1 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Pointer Temperature Controller Thermostat Regulator JTC-903, Temperature Controller For Incubator PID ControllerNegotiableMOQ: 1 -
Temperature Control Controller Industrial Digital Intelligent PID Incubator Temperature Controller REX-C100NegotiableMOQ: 1
-
JTC Series 903/902/905 Digital Pid Intelligent Hot Runner Temperature ControllerNegotiableMOQ: 1
-
220V Digital Air Humidity Control Weather Station WH8040 Humidity Measuring Range Is 1%~99% Temperature and Humidity ControlNegotiableMOQ: 1
-
MH-1210A High Perssion Digital Thermostat Electronic Temperature Control Refrigeration Heating Controller 12V 24V 110V 220VNegotiableMOQ: 1
parameters
| Model number | External dimensions | Perforation dimensions |
| REX-CH102 | 48x48x75 mm | 45 0.50x45 0.50 mm |
| REX-CH402 | 48x96x75 mm | 45 0.50x92 0.50 mm |
| REX-CH502 | 96x48x75 mm | 92 0.50x45 0.50 mm |
| REX-CH702 | 72x72x75 mm | 68 0.50x68 0.50 mm |
| REX-CH902 | 96x96x75 mm | 92 0.50x92 0.50 mm |
| Model number | REX-CH series |
| Accuracy | ±0.5%FS±1°C |
| Supply voltage | CH502S: 220VAC, 50/60 Hz, other omdels: 100-240Vac, 50/60 Hz; |
| Input types | Thermocouple: K, J, R, S, B, E, N, T, W5Re/W26Re, PLII RTD: Pt100, JPt100 Voltage: 0-5V, 1-5V Current: 0-20mA, 4-20mA |
| Output types | Electromagnetic relay + SSR |
| Power consumption | AC100-240V: under 10VA; AC24V: under 5VA; DC24V: under 160mA |
| Control method | PID, or ON/OFF |
| Setting method | Touch switch |
| Indication method | 8-segment 4-digital display and LED indication |
| Alarms | 1. Alarm quantity: Default is 1pcs, if 2pcs, need to be customized 2. Alarm form: N: No alarm A: Deviation low B: Deviation high C: Deviation high/low D: Band E: Deviation high with hold action F: Deviation low with hold action G: Deviation high/low with hold action H: Process high J: Process low K: Process high with hold action L: Process low with hold action |
| Operating temperature | 0 to 50 °C (32 to 122 °F) |
| Operating humidity | 30-85% RH max, non-condensing |
| Alias name | REX-CH series pid temperature controller, intelligent temperature controller |
