QC Series Valve and Door Electric Device

QC fine small electric actuator

QC series valve and door electric device

An overview of the

The 12-drill Ff series valve electric device is unique in design, beautiful on the outside and firm on the inside, and has a long service life

Ten times of the national standard, like a diamond when used, as a ten. Valve electric device series of products with excellent performance, indisputable excellence

Have CE, CSA product certification.

Free bracket, coupling model for our company's latest patent products, make the electric device smaller, lighter, more stable, more precise, more economic!

1. Strong function: intelligent, proportional, switch type. All kinds of signal output types are available.

2, small size: volume and weight is only equivalent to about 35% of similar products.

3. High standard protection: F68 high standard protection grade, indoor and outdoor, mountain and sea, omnipotent.

4. Reliable performance: bearing and electrical components and other key parts are imported famous brand products.

5. Beautiful and generous: aluminum alloy die-casting shell, fine and smooth, and can reduce electromagnetic interference.

6. Precision wear resistance: worm gear output shaft - body special steel alloy forging, high strength. Good wear resistance.

7. Minimal return error: worm gear output shaft-body. Key join gaps are avoided. High transmission accuracy.

8. Safety guarantee: 1500V attached pressure test, F class insulated motor, safety guarantee.

9, simple supporting: the use of single-phase power supply, external line is particularly simple, AC380V is also our strengths.

10. Easy to use: no oil, no point inspection, waterproof and rust proof. Install at any Angle.

11. Protection device: double limit, overheat protection. Overload protection selection function).

12, a variety of speed: full travel time seconds, 10 seconds, 15 seconds, 30 seconds, 60 seconds, etc. (need to specify).

13 integration: intelligent control module is highly integrated in the body of the electric device, without external locator, etc.
