Torsion Wire Spring U Steel Spring Flat Wire Coil 19mm
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Agent
Year Established:
2011
Annual Export Value:
Below US$1 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Oil Tempered Spring Steel Wire 2.45 mm Tension Springs For WireNegotiableMOQ: 1 -
EN10270-3 Stainless Steel Spring Wire PriceNegotiableMOQ: 1
-
0.1mm Very Thin Stainless Steel Piano WireNegotiableMOQ: 1
-
Galvanized Carbon Steel Spring Wire Steel Spring Wire For MattressNegotiableMOQ: 1
-
En10089 Oil Tempered Spring Steel Coil Wire Oil Spring Metal WireNegotiableMOQ: 1
Product Description
Oil tempered spring steel wire
Application: Mechanical springs, Auto application spring wires etc.
Diameter: 0.2-17.0mm Polular
Standard: EN10270-2
Packing: General coil, General coil on carrier,catch weight coil.
| Grade | C | Cr | Si | Mn | P Max. | Cu Max. | V |
| VDC | 0.60-0.75 | * | 0.15-0.30 | 0.50-1.00 | 0.020 | 0.06 | 0.15-0.25 |
| VDCrV | 0.62-0.72 | 0.40-0.60 | 0.15-0.30 | 0.50-0.90 | 0.025 | 0.06 | 0.15-0.25 |
| VDSiCr | 0.50-0.60 | 0.50-0.80 | 1.20-1.60 | 0.50-0.90 | 0.025 | 0.06 | 0.15-0.25 |
| TDC | 0.60-0.75 | * | 0.10-0.35 | 0.50-1.20 | 0.020 | 0.10 | 0.15-0.25 |
| TDCrV | 0.62-0.72 | 0.40-0.60 | 0.15-0.30 | 0.50-1.90 | 0.025 | 0.10 | 0.15-0.25 |
| TDSiCr | 0.50-0.60 | 0.50-0.80 | 1.20-1.60 | 0.50-0.90 | 0.025 | 0.10 | 0.15-0.25 |
| FDC | 0.60-0.75 | * | 0.10-0.35 | 0.50-1.20 | 0.030 | 0.12 | 0.15-0.25 |
| FDCrV | 0.62-0.72 | 0.40-0.60 | 0.15-0.30 | 0.50-1.90 | 0.030 | 0.12 | 0.15-0.25 |
| FDSiCr | 0.50-0.60 | 0.50-0.80 | 1.20-1.60 | 0.50-0.90 | 0.030 | 0.12 | 0.15-0.25 |
