3.1 SS spring steel wire
Application: Mechanical springs, mattress wire, upholstery wire.
Diameter: 0.2-10.0mm
Polular standard: EN10270-3, DIN17223-3, ASTM A313 and customer standard.
Packing: General coil are packaged in plywood pallet.
Spool are packaged in plywood case.
3.2 Oil tempered spring steel wire
Application: Mechanical springs, Auto application spring wires etc.
Diameter: 0.2-17.0mm Polular
Standard: EN10270-2
Packing: General coil, General coil on carrier,catch weight coil.
| Grade | C | Cr | Si | Mn | P Max. | Cu Max. | V |
| VDC | 0.60-0.75 | * | 0.15-0.30 | 0.50-1.00 | 0.020 | 0.06 | 0.15-0.25 |
| VDCrV | 0.62-0.72 | 0.40-0.60 | 0.15-0.30 | 0.50-0.90 | 0.025 | 0.06 | 0.15-0.25 |
| VDSiCr | 0.50-0.60 | 0.50-0.80 | 1.20-1.60 | 0.50-0.90 | 0.025 | 0.06 | 0.15-0.25 |
| TDC | 0.60-0.75 | * | 0.10-0.35 | 0.50-1.20 | 0.020 | 0.10 | 0.15-0.25 |
| TDCrV | 0.62-0.72 | 0.40-0.60 | 0.15-0.30 | 0.50-1.90 | 0.025 | 0.10 | 0.15-0.25 |
| TDSiCr | 0.50-0.60 | 0.50-0.80 | 1.20-1.60 | 0.50-0.90 | 0.025 | 0.10 | 0.15-0.25 |
| FDC | 0.60-0.75 | * | 0.10-0.35 | 0.50-1.20 | 0.030 | 0.12 | 0.15-0.25 |
| FDCrV | 0.62-0.72 | 0.40-0.60 | 0.15-0.30 | 0.50-1.90 | 0.030 | 0.12 | 0.15-0.25 |
| FDSiCr | 0.50-0.60 | 0.50-0.80 | 1.20-1.60 | 0.50-0.90 | 0.030 | 0.12 | 0.15-0.25 |
Oil-quenched spring steel wire is an alloy spring steel wire, which is characterized by good fatigue resistance and resistance to elastic decline. It is suitable for making springs such as valve springs that require good fatigue performance and high alternating frequency. After the spring is formed, only tempering is required.
3.3 Carbon spring steel wire
Application: Mechanical springs, mattress wire, upholstery wire.
Diameter: 0.2-17.0mm Polular
Standard: EN10270-1
Packing: General coil, Z2, Z3,catch weight coil.
| Grade | C | Si | Mn | P Max. | S Max. | Cu Max. |
| SL | 0.35-1.0 | 0.10-0.30 | 0.5-1.20 | 0.035 | 0.035 | 0.20 |
| SM | 0.35-1.0 | 0.10-0.30 | 0.5-1.20 | 0.035 | 0.035 | 0.20 |
| SH | 0.35-1.0 | 0.10-0.30 | 0.5-1.20 | 0.035 | 0.035 | 0.20 |
| DM | 0.45-1.0 | 0.10-0.30 | 0.5-1.20 | 0.020 | 0.025 | 0.12 |
| DH | 0.45-1.0 | 0.10-0.30 | 0.5-1.20 | 0.020 | 0.025 | 0.12 |
| 72A | 0.69-0.76 | 0.15-0.35 | 0.30-0.60 | 0.040 | 0.030 | * |
| 82B | 0.79-0.86 | 0.15-0.35 | 0.60-0.90 | 0.040 | 0.030 | * |
Precision Brand Music Wire is spring tempered and made from high carbon steel alloy.
High tensile strength and high fatigue resistance.
Applications include springs, wire forms, control linkages, armature binding, ceramic cutting, and a variety of industrial uses.
