Product Description
Product Description

Galvanized Steel Wire For ACSR
Size: 1.24mm - 5.50mm
Standard: EN50189; IEC888; BS4565; IS398-PartII etc.
Packaging: Catch weight coil, big rosette coil, Z2coil, Z3 coil.
Application:for mechanical reinforcement in manufacture of aluminum conductor
Class: ST1A, ST2B, ST3D, ST4A, ST5E, ST6C
| Norminal | Max.Dia | Tolerance | Stress at 1% extension |
T.S | Elongation | Torsion |
| mm | mm | mm | Mpa | min. Mpa | min.% | min.turns |
| 1.24 | 1.50 | ±0.03 | 1450 | 1800 | 4 | 14 |
| 1.50 | 1.75 | ±0.03 | 1450 | 1800 | 4 | 14 |
| 1.75 | 2.25 | ±0.04 | 1450 | 1800 | 4 | 14 |
| 2.25 | 2.75 | ±0.04 | 1410 | 1750 | 4 | 14 |
| 2.75 | 3.00 | ±0.05 | 1410 | 1750 | 4 | 12 |
| 3.00 | 3.50 | ±0.05 | 1380 | 1700 | 4 | 12 |
| 3.50 | 4.25 | ±0.06 | 1340 | 1700 | 5 | 10 |
| 4.25 | 4.75 | ±0.06 | 1340 | 1700 | 5 | 10 |
| 4.75 | 5.50 | ±0.07 | 1340 | 1700 | 5 | 10 |
