1. Leading performance: the boom length in full extension is 28m, the performance leading in 5%. The grade ability is 40%, which make the machine have good road adaptability.
2. The unique U boom and plug-in boom head make the load-carrying capacity more balanced, and lift more smoothly.
3. The unique stretch and retract technique prevents the misoperation; the stretch and retract of the boom is safer and more reliable.
4. The control system is optimized by 8 patents; lifting, rotation, and luffing are easy and reliable.
5.Six unique technologies supply the quality assurance, and make the products keep a high value.
6. The innovative jib system adopts embedded block, plug-in boom head and octagon jib, which has excellent lifting performance and safe and reliable lifting work.
7. The unique stretch and retract technique avoids the bend of the core pipe and cylinder and the break of the boom caused by misoperation, improving the safety of the operations.
8. Eight patent techniques ensure the smooth, high efficiency and energy conservation of the lifting, rotation, and luffing systems.
9. Adopt the new hydraulic motor with big torque starting point, making the secondary lifting safer.
10.The humanity design makes the cab and control cab more spacious, and easy to operate.
| 12T | |
| Chassis | Tang Jun Ou Ling truck crane special chassis. |
| Engine | CY4BK351 |
| tire | 825-20 |
| brake | air brake |
| Direction | Hydraulic boost |
| wheelbase | 3900mm or 4300mm |
| the highest speed | 75Km / h |
| single arm length | 7m |
| the number of boom sections | 6 knots (outer rope) or five knots (with rope inside) |
| Boom structure | outer walking rope or inner walking rope |
| thick section boom size |
outside walking rope: height 60 cm, width: 40 cm; inner walking rope: height 58 cm, width 48 cm. |
| Number of lifting legs | 5 (two legs on the side, and auxiliary hind legs) |
| side leg structure | double leg, unilateral leg span 2 meters (from the body) |
| Outrigger span | 6.25 meters across; longitudinal span: 4.5 meters |
| hydraulic system | dual pump confluence system |
| Fan heat system | air-cooled and water-cooled double fan heat system |
| motor | 15kw |
| double winch | double curved neck plunger motor hydraulic winch |
| large structure | I-shaped steel box large frame |
| Appearance size | length 10230mm; width 2400mm; height 3300mm |
| the total quality | 15000KG |
| 12t | |
| Chassis | Futian Ruiwo Crane Special Chassis |
| Engine | YN38CRE1 |
| tire | 825-20 |
| brake | air brake |
| Direction | Hydraulic boost |
| wheelbase | 3850mm |
| the highest speed | 85km / h |
| single arm length | 7m |
| number of booms | 5 knots |
| boom shape | inner rope |
| thick section boom size | height 58 cm, width: 48 cm |
| Number of lifting legs | 5 (two legs on the side, and auxiliary hind legs) |
| side leg structure | double leg, unilateral leg span 2 meters (from the body) |
| Outrigger span | 6.25 meters across; longitudinal span: 4.5 meters |
| hydraulic system | dual pump confluence system |
| Fan heat system | air-cooled fan heat system |
| motor | 15kw (optional) |
| double winch | double inclined shaft plunger motor hydraulic winch |
| Large structure | large frame of I-steel box |
| the appearance size | length 9800mm; width 2200mm; height 3200mm |
| the total quality | 14500KG |
1. Short delivery time: We are a manufacturer with many advanced and new machine. It ensures we have the ability to carry out the production schedule for punctual delivery.
2. More than 10 years production experience in this industry.
3. All our machine have 1 years warranty.
4.We can accept 1 sets as the first order
5.We can stick customer’s brand on the products if you have request.
Surport OEM mounted truck crane south africa
