FAIR Collaborative Robot Intelligent Welding System Torque Management System
Negotiable
/ Piece
1 Piece(Min.Order)
- 10000 Piece / Pieces per Month
You May Like
Product Description
Product Feature：
FR3EDU | FR5 | FR10 | |
| Payload | 2kg | 5kg | 10kg |
| Working Radius | 637m | 922m | 1305m |
| DOF | 6 | 6 | 6 |
| Repeated Positioning Accuracy | ±0.15mm | ±0.03mm | ±0.05mm |
| Total Weight | ≈13kg | ≈22kg | ≈36kg |
| Control Software Writing | Robot Trajectory Planning IO input/output Drag Teaching Collision Detection | Robot Trajectory Planning IO input/output Drag Teaching Collision Detection | Robot Trajectory Planning IO input/output Drag Teaching Collision Detection |
| Mobile terminal (PAD/ mobile phone) APP | Mobile terminal (PAD/ mobile phone) APP | Mobile terminal (PAD/ mobile phone) APP |
| Man-machine Interaction | It can facilitate human-computer interaction | It can facilitate human-computer interaction | It can facilitate human-computer interaction |
Range of action and speed:
| 1 Shaft | ±175； | ±175； | ±175； |
| 2 Shaft | ﹢85，﹣265； | ﹢85，﹣265； | ﹢85，﹣265； |
| 3 Shaft | ±155； | ±155； | ±155； |
| 4 Shaft | ﹢85，﹣265； | ﹢85，﹣265； | ﹢85，﹣265； |
| 5 Shaft | ±175； | ±175； | ±175； |
| 6 Shaft | ±175； | ±175； | ±175； |
| Maximum Joint Velocity | ±180°/s | ±180°/s | ±180°/s |
Reason and so on:
| Level of protection | IP54 | IP54 | IP54 |
| Noise | <65dB | <65dB | <65dB |
| Installation direction | Any direction | Any direction | Any direction |
| Temperature range | 0-45℃ | 0-45℃ | 0-45℃ |
| Control box size | 342*328*97mm | 342*328*97mm | 342*328*97mm |
| Driver voltage | 48V | 48V | 48V |
| Base diameter | 130mm | 150mm | 190mm |
| In-out | Power supply (24V, 1.5A), digital IO, analog IO, 485 communication | Power supply (24V, 1.5A), digital IO, analog IO, 485 communication | Power supply (24V, 1.5A), digital IO, analog IO, 485 communication |
