12mm 1.2" 25MP Machine Vision FA 0.39% TV Low Distortion Industrial Recognition 8K Camera Megapixel Optical Lenses Automatic CCTV Lens C Mount
High resolution : 25 megapixel cover all 8K & 4K
Large format : 1.2" size covering 1.1", 3/4, 2/3", 1/1.8", 1/2" camera
Low distortion: 0.39% TV / -0.28% Optical low distortion for machine vision
Application : Automation, machine vision, medical, life science, ITS, SMT, AOI
Model |
S12MV1224-25M |
|
Resolution |
25 Megapixel |
|
Format |
1.2" (2.74μm) |
|
Focal Length |
12mm |
|
Max image circle |
Φ19.3mm |
|
Aperture (Close) |
F2.4 Manual iris |
|
Angle of View (°) |
1.2" |
76.2*62.4*55.33 |
M.O.D |
0.1m |
|
Relative Illumination |
81.4% ( WD=300mm F2.8 ) |
|
Distortion |
0.39% ( TV ) ; -0.28% (Optical ) |
|
B.F.L |
18.5mm , WD=600mm |
|
CRA |
6.02° |
|
Size |
Φ50*66.96mm |
|
Projector |
Center ≥200lp/mm; Edge Φ16 ≥160lp/mm |
|
Mount |
C |
|
Weight |
300g |
|
Marks |
AT430~680nm T≥85%; 15G Element |
|
