Help CenterE100 Adaptive Coordinated Traffic Light Controller
Related Products
Features and Advantages
BRT control (optional)
VIP vehicle priority traffic control
Manual phase stepping control
Pedestrian crossing trigger control
Centralized coordinate control by the command center
Multi - periods of fixed time control
Self - adaptive arterial and area coordinate control
Off-line arterial and area coordinate control
Wireless coordinate control via an optional GPS module
Single point self-adaptive control
Actuated/semi-actuated control
Traffic data acquisition and analysis
Malfunction detection and alarm
Yellow flashing and all red modes
Over-voltage protection
Door-opening alarm
Mobile terminal operation (optional mobile phone or pad)
Specifications
| Signal output | 56-Way, extendable to 112-way | ||
| Input detection interface | 28 Vehicle inputs; 8 pedestrian request inputs dry contact or OC transistor output, RJ45 | ||
| Presettable time base schedule | 40 | Presettable stage table | 16 |
| Presettable period table | 16 | Max stage no.for each stage table | 16 |
| Max time periods no.of each period table | 48 | Presettable phase number | 24 |
| Presettable plans | 32 | ||
| Interface Type | |||
| Standard EIA level RS232 | 3, Baud rate: 1200bps-115200bps | ||
| RS485 interface | 1, Used for count-down timer communication | ||
| Network interface | 1, 10M/100M Adaptive | ||
| USB 2.0 interface | 1 | ||
| GPS interface | 1, With GPS time service | ||
| Pedestrian request interface | 2,Dry contact signal (optional) | ||
| Flashing yellow controller interface | 1 For the optocoupler output, 1 is connected to the OC transistor output | ||
