Fflat Chveron Conveyor Belt Steel Cord EP/NN/PN/PIW Rubber Conveyor Belt for General Purpose Use
Textile Carcass Rubber Conveyor Belt for General Purpose useProduct Application:
Textile carcass rubber conveyor belts are suitable for noncorrosivity transportation of different size of materials or packages ,which are widely used in coalmines , mining ,seaport ,metallurgy ,power plant ,chemical industries,casting,building materials,cement and other industries and places which need high speed and high efficient transportation .
Product structure
Textile Carcass Rubber Conveyor Belts are produced with NN or EP fabric carcass and different types of cover rubber , the production procedures are : compound mixing , calendering ,belt buliding , belt vulcanization , inspection and repairing and packing .
Product Features
NN fabric conveyor belts have features of light in weight ,high flexbility ,high strength , impact resistance , good troughability , suitable for high speed ,mid-long distance, heavy load transportation of different size of materials .
EP fabric conveyor belts have features of high flexbility ,stable in high temperature ,high strength,low elongation ,impact resistance ,good troughability ,suitable for high speed ,mid-long distance, heavy load transportation of different size of materials .
Standdards Applied
DIN 22102
AS1332
GB/T7984-2013
SANS1173
Main tecnical indicatorsDIN 22102
Item |
NN , EP |
|||||
adhesion |
Cover rubber and ply |
Cover thickness >1.5mm |
4.5 N/mm |
|||
Cover thickness <1.5mm |
4 N/mm |
|||||
Ply and ply |
5 N/mm |
|||||
Cover rubber physical property |
Z |
Y |
W |
X |
||
Tensile strength /MPa ≥ |
15 |
20 |
18 |
25 |
||
Elongation at break / % ≥ |
350 |
400 |
400 |
450 |
||
Abrasion loss / mm3 ≤ |
200 |
150 |
90 |
120 |
||
Aging test (70℃ x 168h) |
Not change by more than 25% from the original value |
|||||
SANS1173
Item |
NN , EP |
|||||
adhesion |
Cover rubber and ply |
Cover thickness >1.5mm |
5 N/mm |
|||
Cover thickness <1.5mm |
4 N/mm |
|||||
Ply and ply |
7 N/mm |
|||||
Cover rubber physical property |
N |
C |
A |
M |
||
Tensile strength /MPa ≥ |
17 |
20 |
18 |
24 |
||
Elongation at break / % ≥ |
400 |
400 |
400 |
450 |
||
Abrasion loss / mm3 ≤ |
150 |
150 |
70 |
120 |
||
Aging test (70℃ x 168h) |
Not change by more than 25% from the original value |
|||||
AS1332
Item |
NN , EP |
|||||
adhesion |
Cover rubber and ply |
Cover thickness >1.5mm |
4.8 N/mm |
|||
Cover thickness <1.5mm |
4 N/mm |
|||||
Ply and ply |
6 N/mm |
|||||
Cover rubber physical property |
N |
A |
M |
XCG |
||
Tensile strength /MPa ≥ |
17 |
18 |
24 |
25 |
||
Elongation at break / % ≥ |
400 |
400 |
450 |
450 |
||
Abrasion loss / mm3 ≤ |
150 |
70 |
120 |
110 |
||
Aging test (70℃ x 168h) |
Not change by more than 25% from the original value |
|||||
If any other questions or want to know more , please feel free to contact with us .
