DSR Bearing pillow block bearing NSK NTN Fyh SKF Koyo Pillow Block Bearing Chrome Steel Bearing with Housing Y Insert Bearing Pillow Block Bearings UC204 UC205 UC206 UC207

Pillow block bearing
Model	d mm	D mm	H mm	W kg	Model	d mm	B mm	L mm	W kg	Model	d mm	B mm	L mm	W kg	Model	d mm	B mm	L mm	W kg
UCP309	100	57	22	4.1	UCF205	52	34.1	95	0.8	UCF305	62	38	110	1.1	UCFL201	47	31	113	0.6
UCP310	110	61	22	5.8	UCF206	62	38.1	108	1	UCF306	72	43	125	1.6	UCFL202	47	31	113	0.6
UCP311	120	66	25	7.4	UCF207	72	42.9	117	1.4	UCF307	80	48	135	2	UCFL203	47	31	113	0.5
UCP312	130	71	26	9.4	UCF208	80	49.2	130	1.8	UCF308	90	52	150	2.7	UCFL204	47	31	113	0.5
UCP313	140	75	75	10	UCF209	85	49.2	137	2.2	UCF309	100	57	160	3.4	UCFL205	52	34.1	130	0.6
UCP314	150	78	33	12	UCF210	90	51.6	143	2.4	UCF310	110	61	175	4.5	UCFL206	62	38.1	148	0.9
UCP315	160	82	32	14	UCF211	100	55.6	162	3.6	UCF311	120	66	185	5.5	UCFL207	72	42.9	17.5	1.2
UCP316	170	86	34	18	UCF212	110	65.1	175	4.4	UCF312	130	71	195	6.5	UCFL208	80	49.2	175	1.6
UCP317	180	96	40	20	UCF213	120	65.1	187	5.5	UCF313	140	75	208	7.9	UCFL209	85	49.2	188	1.9
UCP318	190	96	40	24	UCF214	125	74.6	193	6.1	UCF314	150	78	226	9.5	UCFL210	90	51.6	97	2.2
UCP319	200	103	41	29	UCF215	130	77.8	200	6.9	UCF315	160	82	236	12	UCFL211	100	55.6	224	3.1
UCP320	215	108	42	35	UCF216	140	82.6	208	8.1	UCF316	170	86	250	14	UCFL212	110	65.1	250	4
UCP321	225	112	44	35	UCF217	150	85.7	220	8.3	UCF317	180	96	260	16	UCFL213	120	65.1	258	5
UCP322	240	117	46	45	UCF218	160	96	235	21	UCF318	190	96	280	19	UCFL214	125	74.6	265	5.6

Tianjin DSR Bearing can supply you with the broadest possible array of bearings. In addition to Ball bearing, Roller bearing, Needle bearing, Pillow Blocks, we manufacture Flange blocks, Rolling mill bearing, Slide bearing and Water pump bearing. Our unparalleled experience as a total manufacturer and exporter for these industries is essential for the development and application of a premier product line for all general industries.

We pride ourselves on our ability to serve every customer, from backyard mechanics, to independent shop owners, to automotive technicians, to large manufacturing plants. Our Target Industries served are Agricultural Equipment, Cranes, Electric Motors, Gearboxes, Material Handling, Packaging Machinery, Power Tools, Pumps, Railways and Transportation, Robotics, and products for Textile Machinery. Tianjin Bearing Company is a stronger and growing exporter of bearing in China.

In addition to manufacturing commodity-based bearing products, DSR Bearing makes custom bearing solutions for OEM. Tianjin DSR bearing has stringent quality control standards and maintains complete control over supply, using only the highest grade bearing steel.

Our mission is to fully provide for you. Well into our more than Ten years of business, we are confident that you'll find what you're looking for in bearing product here. Please call, email, or stop by for more information.

We have well facilities and complete equipment strong technology and professional after-sales service.

Q1: What does Tianjin DSR Bearing & Manufacturing do? What are your specialties?
A1: With over 15 years' experience, Tianjin DSR Bearing is a manufacturer of a full line of standard ball and roller bearings. Currently, we offer 13 different bearing series which are available across a wide size range, including IDs from 5/64" to 6-1/2″ and ODs from 15/64" to 13-3/4".

In addition, we also make custom, made-to-order ball bearings and roller bearing components that aren't shown on our website or catalog. We have quoted items per print, per sample, and as interchanges for other manufacturer's products.

Q2: What types and styles of bearings do you make?
A2: We make a variety of bearing types, including ball bearings, roller bearings, thrust bearings, combination bearings, pillow block bearings, custom bearing, and more.

Moreover, we can make bearings in many styles and configurations, including single direction, double direction, caged, banded, separated, open, enclosed, full ball compliment, etc.

Q3: Do you offer any unique secondary services?
A3: Besides bearings, we offer a variety of secondary services to our contract manufacturing customers. Our diverse manufacturing capabilities include CNC turning and machining, manual turning and machining, CNC milling, lapping, super finishing, induction welding, laser marking of finished parts, automatic saw cutting, reverse engineering, and CNC grinding, including ID grinding, OD grinding, cylindrical grinding, centerless grinding, surface grinding, and double disk grinding.

Q4: What services separate Tianjin DSR Bearing from other suppliers?
A4: Unlike Tianjin DSR Bearing, some bearing suppliers do not manufacture their own products. Many of them purchase bearings in other factory, and quite often, these suppliers will change their source of supply without informing customers, resulting in quality issues. Tianjin DSR Bearing's products are manufactured in north China manufacturing facility.

In addition, we hold a unique spot in the industry because we are able to combine the capabilities of a large bearing manufacturer with the precision and attention to detail of a small bearing shop. This allows us to offer personalized service, short lead times, on-time delivery, trusted bearing expertise, innovative solutions, top quality products, and more.

Q5: Do you have any industry certifications?
A5: Yes. Upon request, we can provide SGS, material certs, inspection reports, and material trace ability. Please include all certifications you require along with your RFQ, if any.

Q6: What is your privacy policy, return policy, and terms & conditions? Is there a warranty?
A6: We do offer a warranty that says all products are free of manufacturing defects, and depending on the circumstances, we may allow returns with a 25% restocking fee.

Q7: What is your manufacturing process?
A7:  All materials are sourced domestically (i.e., chrome steel, stainless steel, ceramic, bronze, brass, etc.). Individual components for the bearings are machined in-house on our CNC lathes. Machined pieces are sent out locally for heat treating (hardening). Upon return, the pieces are precision machined, washed, and assembled into finished bearings. Bearings are laser marked and either stocked or packaged for shipping.

For Further Information About Our Products or Services, Please Contact Our Sales Team via Phone or Email Today.
