the horizontal automatic cartoning machine
- 1000 Set / Sets per Month
- Xiamen,china
- T/T PayPal Escrow
- 20 days
- Case Packer Pouch Cartoning Line for Packaging Doypack Bags
- Introduction of plastic hollow plaid production line
- Cartoning Machine Monoblock Case Packer for Packaging Butter Bricks
- Auto Bottle Shrink Wrap Packaging Machine
- Semi-Automatic Heat Shrinking Machine
- Automatic Heat Shrink Edge Banding Shrink Packaging Machine
Product Details
Brand Name: | Taifeng | Place of Origin: | China | Model Number: | TF-BM |
Certification: | CE | After-sales Service Provided: | Engineers available to service machinery overseas | Weight: | 1200KG |
Dimension(L*W*H): | 3500X1250X1700mm | Voltage: | 220V-380V | Power: | 1.5KW |
Application: | Apparel, Beverage, Chemical, Commodity, Machinery & Hardware, Medical, Textiles | Condition: | New | Automatic Grade: | Automatic |
Driven Type: | Electric | Packaging Material: | Paper | Packaging Type: | Cartons |
Product Description
Cartoning machine ,if need any more detail please contact with me:
Emily Huang
Email:qztfkj06@qztfkj.com
Tel/wechat/whatsapp:86 13599759727
Quality and after-sales service commitment
The packaging equipment produced by our company. We have ten years of production technology and experience.Main production are packing machine and other packing machineries.The service life of the main equipment provided by the factory is guaranteed for more than 15 years, and it is manufactured strictly according to the standard.
1. Providing free technical consultation;
2. Assist in ordering package materials;
3. Provide free package design drawings(if needed);
4. Free participation in any training courses organized by our company.
5.Remote video guidance.
TF-BP Cartoning Machine Technology
Item | Parameter | Remarks | |
Material type | |||
Cartoning speed
|
50-60 cartons/min
| ||
Carton Requirement | Paper Quality Requirement | 250—400g/m2 | Surface neat and flat, can be absorbed |
Size Range | L(70-250) x W(30X150) x H(15-90) | (L—W—H) | |
Compressed gas source | pressure | ≥0.6MPa | |
Gas consumption | 20m3/h | ||
Power Supply | 220V—380V 50Hz | ||
Main motor power | 1.5kw | ||
Shape size L X W X H | 3500X1250X1700mm | Main Machine Size | |
Net Weight of Machine | 1200kg |
Main performance structure features:
1. Adopt automatic feeding, open carton, into carton, sealing carton and output etc packaging form. The structure is compact and reasonable, and the operation adjustment is simple.
2. Adopting servo / stepper motor and touch screen, PLC programmable control system, man-machine interface display operation is more clear and simple, high degree of automation, more humane.
3. Adopting photoelectric eye automatic detection and tracking system, no product does not suck the carton, to maximize the saving of packaging materials.
4. The packaging range is large, the adjustment is convenient, and the rapid conversion can be realized between various specifications and sizes.
5. When changing the specification, no need to change the mold, just need adjustment.
6. When there is no product, or product is not in correct place, the machine will not push the product when it is idling. When the product is renewed to supply, it will automatically run again by itself. If the product enters the carton not properly, it will stop automatically, and there is main drive motor overload protection device, is safer and more reliable.
7. Automatic show cartoning speed and counting.
8. According to customer requirements, the use of upturned safety shield, easy to operate, beautiful appearance.
9. Can be linked with aluminum-plastic packaging machine, pillow packaging machine, three-dimensional packaging machine, bottling line, filling machine, labeling machine, inkjet printer, online weighing instrument, other production lines and other equipment.
10. Various automatic feeders and carton-entry systems can be designed according to the requirements of the packaging.
11. According to the customer's requirements, the hot melt glue machine can be equipped with hot melt glue spray sealing carton.
