Help CenterHigh Strength Galvanized Bow Shackle
Related Products
-
US Type Drop Forged Anchor D ShackleUS$ 10 - 240MOQ: 2 Pieces -
Stocked 90-102mm Kenter Shackle, End ShackleUS$ 89 - 1800MOQ: 1 Piece
-
Anchor Shackle/crown Shackle for Marine Ship Boat With CCS ABS LR NKUS$ 50 - 150MOQ: 1 Piece
-
Marine Hardware Swivel Parts/ Welded Chain for LiftingUS$ 8 - 100MOQ: 1 Piece
-
102mm LR Black Painted Offshore Kenter Shackle/ Joining ShackleUS$ 70 - 2500MOQ: 1 Piece
TREASURE MARINE EQUIPMENT CO., LTD is a company specializing in anchor chains and accessories, anchors, Mooring Outfittings,hatch cover chains and stainless steel chain products.
Heat treated |
Drop forged, tempered and quenched. |
Material |
Carbon Steel, Alloy steel, Stainless steel. |
Standard |
EUROPEAN TYPE,JIS TYPE,US. TYPE,DIN TYPE. |
Size |
Various or according to customer's design. |
Surface |
Heat treatment, Polishing, shot blasting, Painting, Electro plating, Chemical Plating. |
|
Delivery |
Samples are sent by express. Large quantity products delivered to customer by sea or according to your request. |
| Size (in) | W.L.L (t) | Weight (lbs.) | Dimensions(in) | Tolerance +/- | |||||||||
| A | B | D | E | F | H | L | P | N | D | A | |||
| 3/16 | 1/3 | 0.06 | 0.38 | 0.25 | 0.88 | 0.19 | 0.60 | 0.56 | 1.47 | 0.98 | 0.19 | .06 | .06 |
| 1/4 | 1/2 | 0.11 | 0.47 | 0.31 | 1.13 | 0.25 | 0.78 | 0.61 | 1.84 | 1.28 | 0.25 | .06 | .06 |
| 5/16 | 3/4 | 0.22 | 0.53 | 0.38 | 1.22 | 0.31 | 0.84 | 0.75 | 2.09 | 1.47 | 0.31 | .06 | .06 |
| 3/8 | 1 | 0.33 | 0.66 | 0.44 | 1.44 | 0.38 | 1.03 | 0.91 | 2.49 | 1.78 | 0.38 | .13 | .06 |
| 7/16 | 1-1/2 | 0.49 | 0.75 | 0.50 | 1.69 | 0.44 | 1.16 | 1.06 | 2.91 | 2.03 | 0.44 | .13 | .06 |
| 1/2 | 2 | 0.79 | 0.81 | 0.64 | 1.88 | 0.50 | 1.31 | 1.19 | 3.28 | 2.31 | 0.50 | .13 | .06 |
| 5/8 | 3-1/4 | 1.68 | 1.06 | 0.77 | 2.38 | 0.63 | 1.69 | 1.50 | 4.19 | 2.94 | 0.69 | .13 | .06 |
| 3/4 | 4-3/4 | 2.72 | 1.25 | 0.89 | 2.81 | 0.75 | 2.00 | 1.81 | 4.97 | 3.50 | 0.81 | .25 | .06 |
| 7/8 | 6-1/2 | 3.95 | 1.44 | 1.02 | 3.31 | 0.88 | 2.28 | 2.09 | 5.83 | 4.03 | 0.97 | .25 | .06 |
| 1 | 8-1/2 | 5.66 | 1.69 | 1.15 | 3.75 | 1.00 | 2.69 | 2.38 | 6.56 | 4.69 | 1.06 | .25 | .06 |
| 1-1/8 | 9-1/2 | 8.27 | 1.81 | 1.25 | 4.25 | 1.13 | 2.91 | 2.69 | 7.47 | 5.16 | 1.25 | .25 | .06 |
| 1-1/4 | 12 | 11.71 | 2.03 | 1.40 | 4.69 | 1.29 | 3.25 | 3.00 | 8.25 | 5.75 | 1.38 | .25 | .06 |
| 1-3/8 | 13-1/2 | 15.83 | 2.25 | 1.53 | 5.25 | 1.42 | 3.63 | 3.31 | 9.16 | 6.38 | 1.50 | .25 | .13 |
| 1-1/2 | 17 | 20.80 | 2.38 | 1.66 | 5.75 | 1.53 | 3.88 | 3.63 | 10.00 | 6.88 | 1.62 | .25 | .13 |
| 1-3/4 | 25 | 33.91 | 2.88 | 2.04 | 7.00 | 1.84 | 5.00 | 4.19 | 12.34 | 8.80 | 2.25 | .25 | .13 |
| 2 | 35 | 52.25 | 3.25 | 2.30 | 7.75 | 2.08 | 5.75 | 4.81 | 13.68 | 10.15 | 2.40 | .25 | .13 |
| 2-1/2 | 55 | 98.25 | 4.13 | 2.80 | 10.50 | 2.71 | 7.25 | 5.69 | 17.90 | 12.75 | 3.13 | .25 | .25 |
| 3 | 85 | 154.00 | 5.00 | 3.30 | 13.00 | 3.12 | 7.88 | 6.50 | 21.50 | 14.62 | 3.62 | .25 | .25 |
| 3-1/2 | 120 | 265.00 | 5.25 | 3.76 | 14.63 | 3.62 | 9.00 | 8.00 | 24.88 | 17.02 | 4.38 | .25 | .25 |
| 4 | 150 | 338.00 | 5.50 | 4.26 | 14.50 | 4.00 | 10.00 | 9.00 | 25.68 | 18.00 | 4.56 | .25 | .25 |
Anchor:
anchor generally refers to ship anchor, is the main component of anchoring equipment. Iron stopping equipment, linked to the ship with iron chains, thrown on the bottom of the water or on the shore, can make the ship stop steadily. The ancient anchor is a big stone, or a basket full of stones, called Anchorage. The anchor is tied to the bottom of the water with a rope, and the ship is moored according to its weight. Later, there were wooden claw anchors, that is, wooden claws were tied to both sides of the stones, and the ship was moored by weight and grip. Metal anchors have been recorded in the Southern Dynasty of China. Ancient Chinese sailboats used four-clawed iron anchors, which have excellent performance and are still used in sampans and small boats. Anchor, stopping gear, iron. A section fixed to a ship with an iron chain, with an inverted hook at the other end, thrown to the bottom of the water or shore to stabilize the hull: anchor. This means: the equipment used when a ship is moored. It is usually made of iron or steel. Such as: anchor (one bow anchor on each side of the bow, another anchor, flow anchor and small anchor, etc.), anchor cable (thick rope or chain of anchor), anchor cable, anchor cable Anchor chain hole (there is a small hole on each side of the bow in case the anchor chain is brought in from the hole and the anchor is attached to the outer steel plate). Also refers to a person or thing that can be relied on, eg in times of crisis. We use it as a strong anchor to fasten the soul.
