Indoor Single phase Epoxy Resin Insulation MV Voltage Transformer

FOB Price

USD $10 - $30 / Piece

100 Pieces(Min.Order)

Product Details

Indoor Single phase Epoxy Resin Insulation MV Voltage Transformer

Technical data

◊ The voltage transformers are in accordance with GB1207 and IEC60044-2 standards;

◊ Rated insulation level: 24/65/125kV;

◊ Rated frequency: 50Hz, 60Hz;

◊ Rated secondary current: 5A, 1A.

Type	Class voltage ratio(kV)	Class combination	Accuracy class and rated output(VA)(cosØ=0.8)			Limited thermal output of secondary winding	Weight(kg)
Type	Class voltage ratio(kV)	Class combination	0.2	0.5	1.0	Limited thermal output of secondary winding	Weight(kg)
JDZ9-10(B) JDZ9-6(B)	10/0.1 6/0.1	0.2 0.5 1.0	40	100	200	600	34
JDZF9-10(B) JDZF9-6(B)	10/0.1/0.1 6/0.1/0.1	0.2/0.5	25	40		2X300
JDZU9-10(B) JDZU9-6(B)	10/0.1/0.22 6/0.1/0.22	0.2 0.5 1.0	30	60	100	400

NOTE: if user's data go beyond the above mentioned scope, please contact us for negotiation and confirmation.
