Weichai WP7 Marine Engine and Spare Parts Weichai 110-220KW

Weichai WP7 Marine Engine and Spare Parts Weichai 110-220KW thumbnail-1
Weichai WP7 Marine Engine and Spare Parts Weichai 110-220KW photo-1
US$ 11 - 1111 MOQ: 1 Piece
Key Specifications
Get Latest Price
Brand Name:
WEICHAI
Place of Origin:
China
Model Number:
WP2
Contact Supplier Request Quote Chat Now
Shandong Hongfan Power Technology Co.,Ltd
Verified Business License
Payment & Shipping
Payment Methods:
Port of Shipment:
QINGDAO
Delivery Detail:
7 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name WEICHAI
Place of Origin China
Model Number WP2
Certification CE
After-sales Service Provided Engineers available to service machinery overseas
Warranty 1500HOURS
Weight 111
Dimension(L*W*H) 1111
Condition New
Fuel Diesel
Start Electric Start
Cold Style Water-Cooled
Stroke 2 Stroke
Usage Boat
Cylinder Multi-cylinder

Parameters Table

Type Four-stroke, water cooled, in-line, turbocharged and intercooled Number of cylinders 6
Cylinder Bore/stroke 108×136(mm) Displacement
 7.47L
Oil consumption rate ≤0.2g/kW·h Noise  ≤97dB（A）
Minimum fuel consumption rate 192g/kW·h Idle speed 700±50r/min
Torque reserve 20-35% Net weight 850kg
Rotation direction of crankshaft
(facing the flywheel end) 		Counter-clockwise Emission standard
 IMO TIER II

Dimensions

 Length × Width × Height 1398×865×980（mm）

Model Portfolio Table

Series Model Air intake mode Rated power kW/Ps Speed
r/min		 Fuel feeding mode Emission level Power classification
WP7 WP7C150-15E120 Turbocharged and intercooled 110/150 1500 HPCR IMOⅡ P1
WP7C240-18E120  Turbocharged and intercooled 176/240 1800 HPCR  IMOⅡ P1
WP7C268-18E120 Turbocharged and intercooled 197/268 1800 HPCR IMOⅡ P1
WP7C278-21E120 Turbocharged and intercooled 205/278 2100 HPCR IMOⅡ P1
WP7C300-22.5E120 Turbocharged and intercooled 220/300 2250 HPCR IMOⅡ P2

Remark: Product parameters and model portfolio are for reference only. Please contact relevant personnel for official information on delivery time and fishing boat model portfolio.

Product description

　　Safe and reliable

  • The high-strength design of structural parts such as engine block, piston and bearing bush ensures the reliability of diesel engine under high explosion pressure

  • For turbocharger, starter, high-pressure oil pump and other important parts, global excellent suppliers are used

  • Withstand the most stringent durability test and assessment; ensure the reliability of key parts and components; and the overhaul period of the whole engine is over 12000h

  • Perfect self-diagnosis system, perfect failure protection mode, and safe control strategy

　　Strong power

  • Accurate control by electronic control units, high injection pressure, small fluctuation of rotating speed, and strong power

  • Low-speed and high-torque design with the torque reserve of 20%-35%, quick response, and fast speed increase

　　Economical and fuel-efficient

  • The fuel injection law is optimized, the fuel injection pressure, fuel injection quantity and fuel injection time are accurately controlled, the fuel is fully atomized, and the minimum fuel consumption rate is 192g/kW•h

　　Comfortable and environmentally friendly

  • It can realize multiple injections such as pre-injection and post-injection, and the noise and vibration are reduced by 20% compared with the mechanical pump system

  • Water jacket exhaust pipe and water jacket exhaust tail pipe are used to reduce engine compartment temperature

  • IMOⅡ ship emission standards are met

　　Strong practicability

  • LCD Internet instruments, vibration isolators, and hand-pressed oil well pumps can be equipped to meet the requirements of different customers

  • Horizontal air filter and rear turbocharger reduce the height of the whole engine and facilitate the layout of the engine compartment

  • Different control strategies are adjusted according to different performance requirements

  • Receive/output various control signals, which meet the requirements of automation control


Product Tags: weichai WP6 , MARINE ENGINE , WEICHAI ENGINE
