Micro 40mm 4pin Pwm Speed Control Brushless 12v dc 40x40x28mm 4028 4pin Pwm Equipment Cooling Fan
US$ 3.8 - 4.2
MOQ: 200 Pieces
Key Specifications
Get Latest Price
Brand Name:
Realfield
Place of Origin:
China
Model Number:
HXD402812M
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
10 days
Related Products
-
60mm Hydraulic Bearing Axial Ventilator Fan Blower 5v dc 60x60x15mm 6015 CoolerUS$ 0.88 - 1.08MOQ: 500 Pieces -
20mm 20x20x6mm 2006 dc 3v 3.7v 5v Micro Axial Ventilador Pcb Cooling FanUS$ 2.4 - 2.6MOQ: 1000 Pieces
-
2cm 20mm Ventilateur 20x20x6mm 2006 dc 3v 3.7v 5v 12v Micro Axial Ventilador Cooling Fan LfterUS$ 2.4 - 2.6MOQ: 1000 Pieces
-
20mm Micro Lfter 20x20x10mm Mini Ventilateur 12v dc 2010 Panel Axial Cooling FanUS$ 1.8 - 2.2MOQ: 1000 Pieces
-
25mm Micro Lfter 25x25x7 12v dc Ventilateur 2507 Mini Cooling FanUS$ 0.9 - 1.1MOQ: 500 Pieces
Brand Name
Realfield
Place of Origin
China
Model Number
HXD402812M
Certification
CE, ROHS
After-sales Service Provided
No overseas service provided
Voltage
DC 12v
Power
4.32W
Speed
13000RPM
Air Volume
23.2CFM
Blade Material
Plastic
Mounting
Free Standing
Electric Current Type
DC
Micro 40mm 4pin pwm speed control brushless 12v dc 40x40x28mm 4028 4pin pwm equipment cooling fan
| Model | Bearing Type | Rated Voltage | Operating Voltage Range | Rated Current | Rated Input Power | Speed | Maximum Air Flow | Maximum Air Pressure | Noise | Weight | ||
| PART NO. | B/S/Y | VDC | VDC | AMP | WATT | RPM | m3/min | CFM | mmH20 | INH20 | DB-A | g |
| HXD402812LL | B/S/Y | 12 | 6.0 to 13.5 | 0.12 | 1.44 | 8000 | 0.36 | 13.2 | 8.6 | 0.34 | 33.2 | 38 |
| HXD402812L | B/S/Y | 12 | 6.0 to 13.5 | 0.18 | 2.16 | 10000 | 0.46 | 16.8 | 10.8 | 0.52 | 36.8 | 38 |
| HXD402812M | B/S/Y | 12 | 6.0 to 13.5 | 0.36 | 4.32 | 13000 | 0.62 | 23.2 | 13.4 | 0.88 | 41.5 | 38 |
| HXD402812H | B/S/Y | 12 | 6.0 to 13.5 | 0.42 | 5.04 | 17000 | 0.72 | 25.8 | 16.6 | 1.18 | 57.8 | 38 |
| HXD402824LL | B/S/Y | 24 | 18.0 to 26.5 | 0.06 | 1.44 | 8000 | 0.36 | 13.2 | 8.6 | 0.34 | 33.2 | 38 |
| HXD402824L | B/S/Y | 24 | 18.0 to 26.5 | 0.1 | 2.4 | 10000 | 0.46 | 16.8 | 10.8 | 0.52 | 36.8 | 38 |
| HXD402824M | B/S/Y | 24 | 18.0 to 26.5 | 0.18 | 4.32 | 13000 | 0.62 | 23.2 | 13.4 | 0.88 | 41.5 | 38 |
| HXD402824H | B/S/Y | 24 | 18.0 to 26.5 | 0.26 | 6.24 | 17000 | 0.72 | 25.8 | 16.6 | 1.18 | 57.8 | 38 |
