Whole sales industrial cellular 4g router

Name: Whole sales industrial cellular 4g router
Brand: Alotcer
Price: USD $125 - 130 / Piece

FOB Price

USD $125 - $130 / Piece

1 Piece(Min.Order)

Supply Ability 6543 Piece / Pieces per Month
Port Xiamen
Payment Terms:T/T L/C D/P D/A Credit Card PayPal Cash Escrow
Delivery Detail:7 days

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Brand Name:	Alotcer	Place of Origin:	China	Model Number:	AR7088H-ASP
Type:	Wireless	Certification:	ISO9001, CE, Sgs	Function:	Firewall, QoS, VPN
Products Status:	Stock	Application:	Enterprise	WAN Ports:	1
LAN Ports:	3

Product Description

3 Lan AR7088H router

► 3 lan ports, dual serial ports, dual cards, support DIN rail and mount kit installation
► 7 mode full band, China Mobile, China Unicom, and China Telecom are fully compatible
► 5G/4G network to meet big data communication transmission
► Wired multi-channel backup to make transmission more secure
► Efficient and stable VPN channel to ensure data security and reliability
► High standard industrial design, -40 °C ~ 80 °C cold resistance, high temperature resistance , anti-interference
► 24 hours uninterrupted work, ensuring smooth communication links
► Industry innovative user configuration information anti-lost mechanism, more stable operation
► Efficient remote device management, easy to install and user-friendly interface
► State Grid network encryption, GPS, Lora, BDS and other hardware and software customization and services
► Cloud services, support operation and maintenance of itself and remote terminal
Specification

Items		Contents
Hardware System	CPU	Industrial 32 bits CPU
	FLASH	16MB (Extendable to 64MB)
	SDRAM	128MB

Interface	Serial	1 RS232 and 1 RS485, 15KV ESD protection Serial port: 5 PIN industrial terminal, 3.5mm pitch Data bits: 5, 6 ,7, 8 Stop bits: 1, 1.5(optional), 2 Parity: none, even, odd, space, mark Baud rate: 110~230400 bps Large serial port data cache:10MB
	WAN/LAN	1 10/100Mbps WAN(RJ45,can configurable as LAN) port, auto MDI/MDIX, 1.5KV magnetic isolation protection
	LAN	2 10/100Mbps Ethernet ports(RJ45), auto MDI/MDIX, 1.5KV magnetic isolation protection
	Antenna	Cellular/GPS: Standard SMA female interface, 50 ohm WIFI: Standard SMA male interface, 50 ohm
	SIM/UIM	Standard 3V/1.8V user card interface, 15KV ESD protection
	Power	2 PIN industrial terminal, 3.81mm pitch, reverse- voltage and over voltage protection
	Reset	Press this key for 8 seconds to restore the Router to its original factory default settings
	Indicator	“PWR”、”SIG”、”NET”、”APP” 、”Link”(RJ45)

Network	Wireless Network	GSM/GPRS/EDGE: 850/900/1800/1900MHz CDMA: 800/1900MHz WCDMA/HSUPA/HSPA+: 850/900/1900/2100MHz CDMA2000 1x/ EVDO Rev. A: 800/1900MHz TD-SCDMA: 1880-1920/2010-2025MHz(A/F) TDD-LTE:Band 38/39/40/41& Band 61/62 (Private Network) FDD-LTE:Band1/2/3/4/5/7/8/12/13/17/18/19/20/21/25/26/28/66
	PPP Protocol	Support PPP Protocol
	PPP Heartbeat	Maintaining links with the cellular network to prevent forced sleep, to ensure the stability of dial-up link.
	Network Authentication	Support CHAP/PAP Authentication
	TCP Heartbeat	Monitor the server connection

Highlights

Related Products

Company Profile

Xiamen Alotcer Communication Technology Co., Ltd.

As a senior networking experts, Xiamen Alotcer Communication Technology Co., Ltd. is a professional M2M, Things communications products and solutions provider. Deep rooted Networking Wireless Communications for many years, both from the quality of the product and the company's scale are in the industry-leading level. We have obtained SGS certification and are ISO9001 certified, along with CE, FCC, EMC, ROHS, environmental testing and National Network Center certifications.

Our Srevices

 Our service:
---Any inquiry will be replied in 24 hours
---OEM&ODM, We can customize products according to your requirements;
---Monthly output over 10,000 pcs;
---All of our products provide a 2 years warranty.

 About sample:
---Sample is available;
---Sample lead time: 2-3 working days, 4-5 days with customized logo;
---More details, please contact with us.

 Payment methods:
---Payment Type: T/T, L/C, D/P D/A, MoneyGram, Credit Card, PayPal, Western Union, Cash, Escrow;
---Payment Currency: USD, EUR, JPY, CAD, AUD, HKD, GBP, CNY, CHF;

 Shipping & Delivery terms:
---Shipping methods: By sea, air, or UPS, FEDEX, EMS, DHL, TNT, etc;
---Delivery Terms: FOB, CFR, CIF, EXW, FAS, CIP, FCA, CPT, DEQ, DDP, DDU, Express Delivery, DAF, DES；
---Delivered time: 2-3 business days for sample, 20-25 days for mass order.

FAQ

1. who are we?
We are based in Fujian, China, start from 2014,sell to Domestic Market(55.00%),Southeast Asia(10.00%),Central America(8.00%),Southern Europe(7.00%),South Asia(5.00%),South America(5.00%),Western Europe(3.00%),North America(1.00%),Oceania(1.00%),Africa(1.00%),Northern Europe(1.00%),Eastern Europe(1.00%),Mid East(1.00%),Eastern Asia(1.00%). There are total about 201-300 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
Industrial Cellular Router,Industrial embedded Cellular Router,Industrial IP Modem,Industrial Modem,Monitoring Platform

4. why should you buy from us not from other suppliers?

Main industrial router vendor for China National Power Grid. Industrial 5G/4G cellular router/Modem Manufacturer for Worldwide. Alotcer have passed ISO9001. Product have CE certification.More than 200 people with more than 30% RD and technical.

5.Do you....?

Maybe, why don't contact us now! Inquring us to see if we can, or if we do, to see if we can suprise you!
