twin-screw extruder feed machine gearbox use M3CT2990 bearing factory 28x90x98mm
Tandem Thrust Bearings M3CT2990 can receive heavy load in a limited space and support firmly in the direction of axis and last long with low frictional power. In addition, these bearings are moved by oil lubrication. Also these tandem thrust bearings are used principally in gear boxes for single & twin screw extruders in the rubber and plastic industries. Tandem bearings are predominantly fitted with standard axial cylindrical roller and bearing assemblies. The thrust cylindrical roller bearing M3CT2990 with size 28x66x82mm , the inner diameter:28 mm, the outer diameter:90mm, the total height:82mm
Tandem bearing |
Basic size unit(mm) |
Basic load rating Unit (KN) |
|||
Inner dia |
Outer dia |
Height |
Cr |
Cor |
|
M3CT2990 |
28 |
66 |
82 |
336 |
1411 |
Tandem Bearings Type
1. Basic Type: The bearing adopts elastic spacer to connect the shaft washer,housing washer, roller and cage assembly. The components of this Thrust Bearings are demountable. The user should assemble or dismount the bearing meticulously according to our guide book.
2. Shaft Type: The bearing is made by penetrating an axis through the inner bore of basic type bearing and fastening the bearing to the axis by locking collar/snap ring. The components of this type bearing are inseparable. Shaft type tandem bearing is variational structure of basic type.
3. Multi-stage cylindrical roller thrust bearing (sleeve type) locking collar is made by covering a sleeve to the external of the basic type multi-stage cylindrical roller thrust bearing. It is also inseparable,and is assembled and disassembled as a whole.
