Home > Products > shot blasting machine > Automatic Feeding Crawler Belt Shot Blasting Machine for Brass
Automatic Feeding Crawler Belt Shot Blasting Machine for Brass
- Qingdao port or as customer's requirement
- T/T L/C D/P D/A Credit Card Cash Other
- 15 days
You May Like
-

                        Hot Box Sand Core Shoot Machine for Faucet Production
-

                        Foundry Plant Hot Box Shoot Core Machine for Shell Making
-

                        Cold Box Sand Core Shooting Machine for Brake Disk Production
-

                        Horizontal Parting Sand Shoot Core Machine China Factory
-

                        Hydraulic Green Sand Molding Machine for Large Dimension Workpiece
-

                        High Efficiency Hydraulic Green Sand Molding Machine With Multi Piston
Product Details
| Brand Name | bestech | Place of Origin | China | |
| Model Number | Q3210 | Use | Burnishing, Descaling / Stripping | |
| Certification | CE | After-sales Service Provided | Overseas service center available | |
| Dimension(L*W*H) | 1250*5600*2580 | Feature | Non-Ionic, Non-Toxic, Rust / Corrosion Inhibitor | |
| Fuel | Electric | Condition | New | |
| Power(W) | 12.6kw | Material | Metal / Coil | |
| Industry Used | Other, shot blasting | Cleaning Type | Clean-In-Place (CIP) | |
| Cleaning Process | Other, steel abrasive material |
Product Description
This machine can be used to derust and streng then the surface of workpieces with mass productions.The workpieces must accept collision.This series machines can be singlely used or together with others.
This machine is in keeping with many species,big medium the batch quantity produces the durface of the workpiece in addition to becoming rusty or throwing the pill to enhance.Tidy up the workpiece and the hot processing pieces that musts be the not afraid collisiom.That machine since can single machine usage,can go together with the line usage again.
The projectile and sand particles flow into the screw conveyor at the bottom from the holes in the track, and are fed into the hoist by the screw conveyor, and separated by the hoist into the separator.After being filtered by a fan, the dust containing gas is sucked into the dust collector and discharged into the atmosphere. The dust is blown back into the dust collector at the bottom of the dust collector through the air, and the user can clean it regularly.Waste sand from the waste pipe, the user can reuse.The shot sand mixture is recycled into the chamber by the recycle tube and reused after the separator is separated. The layout of the shot blasting device is simulated by 3d computer dynamic simulation, and all the layout angles and positions are determined by computer design.On the basis of taking care of all the work pieces to be cleaned, minimizing the empty throwing of the projectile, thus maximizing the utilization rate of the projectile and reducing the wear of cleaning the indoor protective plate.
| Item | units | Q326C | QR3210 | 15GN | 28GN |
| productivity | t/h | 0.6-1.2 | 1.5-2.5 | 5-6 | 10-12 |
| feeding amount | kg | 200 | 600 | 1300 | 3500 |
| max.weight of single piece | kg | 10 | 30 | 230 | 363 |
| diameter of end disk | mm | 650 | 1000 | 1092 | 1245 |
| efectve volume | m3 | 0.15 | 0.3 | 0.43 | 0.79 |
| shot-blasting capacity | kg/min | 100 | 250 | 480 | 700 |
| air volume for dedusting | m3/h | 2200 | 5000 | 5300 | 6500 |
| power consumption | kw | 12.6 | 24.3 | 49.3 | 64.5 |
| outline dimension | mm | 3681*1650*5800 | 3972*2600*4768 | 4597*3262*5709 | 5300*5432*6814 |
1. Reply your inquiry in 24 working hours.
2. Experienced staffs answer all your questions in fluent English.
3. Customized design is available. UEM&UBM are welcomed.
4. Exclusive and unique solution can be provided to our customer by our well-trained and professional engineers and staff.
5. Special discount and protection of sales are provided to our distributor.
6. Professional factory : We are manufacturer, specializing in producing all kinds of machinery for more than 20 years, competitive with good quantity.
7.Sample: We can send out sample for test in one week if the order quantity is big enough. But the shipment charges is usually paid by your side, the charges will be rebounded when we have formal order.
8.As an honest seller, we always use superior raw material, advanced machines, skilled technicians to ensure our products to be finished in high quality and stable feature. Welcome to contact us or visit our company.
Q:How many days will be used to produce this shot blasting machine?
A:Normally within 15 workdays or according to your requirement
Q:Can you provide installation and commissioning overseas?
A:We can supply oversea service if needed
Q:Are you manufacture or trading company?
A:We are manufacture,welcome to visit our factory
