16dBi 2300-2700MHz MIMO Directional Panel Sector Antenna

16dBi 2300-2700MHz MIMO Directional Panel Sector Antenna

•


Electrical specifications
• Frequency range (MHz): 2300～2700


• Polarization: vertical and horizontal


• Gain (dBi): 2×16


• Half-power beam width (°) : H: 120, V:7


• Front-to-back ratio (dB): ≥18


• Input impedance (Ω) 50


• VSWR: ≤1.5


• Isolation between ports (dB): ≥28


• Maximum input power (W) 200


• Lightning protection DC ground



Mechanical specifications

• Input connector type: 2-N female


• Dimensions (mm) (height/width/depth): 1200*114*54


• Packing size (mm): 1280*155*145


• Antenna weight (kg): 6


• Radome material: UPVC


• Radome color: Gray


• Mechanical tilt (°): 0～10


• Operating temperature (°C) -40～60


• Rated wind velocity (m/s): 60


• Mounting hardware (mm): ￠35～￠75

•
