XPS foam board production line
XPS foamed board, has a perfect closed-pore alveolate structure.Its density, water absorption, coefficient of heat conducting and the coefficient of steam pervasion are all lower than those of other board heat preservation materials.
They have the characteristics of strong intensity, light material, airtight, anticorrosion, resistance, low cost, etc.
It has been widely used in the fields of heat preservation and heat insulation in the construction industry, frost resistance of the highway, airport and household fitment, It is the generally acknowledged and the best heat preservation material.
The complete machine adopt PARTNER’S sole possession of the new design, the elegant appearance, the craft operation is simple, but has the high output.
Model |
Screw diameter and L/D ratio |
Board |
Capacity |
Power |
Dimension |
|
Width/mm |
Thickness/mm |
|||||
SFBZ-100/120 |
100-32D 120-42D |
600 |
20-70 |
180m3/d |
180kw |
38*6*5m |
SFBZ-135/150 |
135-32D 150-42D |
600/900/1200 |
20-120/80/60 |
350m3/d |
260kw |
48*10*5m |
SFBZ-150/75*2 |
75-40D 150-42D |
600/900/1200 |
20-120/80/60 |
360m3/d |
280kw |
48*10*5m |
SFBZ-170/200 |
170-30D 200-34D |
600/900/1200 |
20-150/150/80 |
450m3/d |
520kw |
58*8*5m |
CO2-135/150 |
135-32D 150-42D |
600/900/1200 |
20-70 20-120/80/60 |
300m3/d |
290kw |
48*10*5m |
CO2-200/75*2 |
75-40D 200-32D |
600/900/1200 |
20-70 20-120/80/60 |
300m3/d |
490kw |
68*10*5m |
CO2-200/85*2 |
85-40D 200-36D |
600/900/1200 |
20-70 20-120/80/60 |
400m3/d |
560kw |
78*10*5m |
Contact: IVY zheng Tel/wechat/whatsapp:0086-13375559166 Email: sales@pt-qd.com
