YN27C Gasoline Type of Rock Drilling Machine
Features of YN27 internal combustion rock drill
1. The YN27 hand-held internal combustion rock drill is a hand-held rock drilling tool that is composed of a small gasoline engine, a compressor, and a rock drill.
2. During operation, the compressed air produced by itself blows away the rock dust in the blasthole.
3. The weight of the host is only 27KG, and it is easy to carry. It is suitable for areas with high mountains, no power supply, and no wind pressure equipment. It is especially suitable for temporary projects with greater mobility. To
YN27 Internal Combustion Rock Drill Use
1. This machine is suitable for rock drilling and crushing, and is widely used in national defense projects, mines, road construction, urban construction, quarrying and other earth and stone projects.
2. It has a wide range of applicability, and it can work in high mountains, plains, and ±40°C areas.
The YN27 internal combustion type rock drill is suitable for rock drilling. If a few parts are replaced, it can be changed into a crusher and tamping machine for various crushing, shoveling, digging, splitting, tamping and other tasks.
No matter in high mountains or flat land; no matter in the extreme heat of +40°C or the severe cold area of -40°C, you can work. This machine has a wide range of adaptability
YN27C GASOLINE ROCK DRILL | |
Model |
YN27C |
Weight |
27kg |
|
Engine load speed (determination of when chiseled five hole) |
≥2450r/min |
Drill rod idling speed |
≥200r/min |
The tail bit shank size drill rod |
22x108mm |
Deepest depth of the borehole |
≥6m |
Tank capacity |
≥1.14L |
Drilling speed |
≥250mm/min |
Gasoline and lubricating oil blending ratio |
9:1 |
Spark plug electrode gap |
0.5~0.6mm |
Gasoline Type of Rock Drilling Machine
Hand held gasoline rock drilling rock drilling machine YN27C
1. Very compact structure, Less of the-easy-to-damage-parts, very easy to control. It can adapt to these outside situations there is no water and no electronic power.
2. It is a Kind hand held drill built up with gasoline engine, Air pump, rock drill and the rotation plumbum equipment for running or stop.
3. It can be used for breaking, drilling, blasting, tamping splitting and ramming.
| Type | YN27C |
| Weight of main machine | 27kg |
| Overall dimensions(L*W*H) | 746*315*229mm |
| Type of engine | Single cylinder, air cooled two strokes |
| Cylinder diameter*stroke of piston | Φ58*70mm |
| Rotation speed of engine | ≥2450rpm |
| Displacement of engine piston | 185cm³ |
| Type of carburetor | hand needle valve, floatless type |
| Ignition system | controllable silicon, contactless system |
| Drilling speed (mean value of five holes) | ≥250mm/min |
| Drilling hole diameter | 28-42mm |
| Max drilling depth | 6m |
| Fuel consumption | ≤0.12L/m |
| Tank capacity | ≥1.5liter |
| Mixture ratio of gasoline and lubrication oil (in volumes) | 12:01 |
| Drill rod and breaker shank | Hex22*108mm |
| Rotating speed of drill rod | ≥200rounds/min |
| Clearance of spark plug | 0.5-0.7mm |
Power, performance, punch and portability
• Breaking, cutting and drilling capabilities
• Ideal for tie tamping, drilling, anchoring, asphalt and concrete cutting
• Petrol driven, no need for cables, power packs, hosers or compressors
• Easy to transport, use, maintain and service
• Cuts capital, running, transport and storage costs
