General description
Cup Heap Pin with insulation consist of a copper or galvanized coated steel shank partly
insulated and firmly crimped on a galvanized steel washer head , with an insulated
underhead . It allow the fixing of aluminum faced insulation or wired mattress on sheet
metal such as airducts , metal beams , metal industrial equipment etc . in a single operation .
Cup Head Pin without insulation is suitable for plain insulation(without aluminum facing)
It is used with welding machine
Shank |
Material |
copper or galvanized coated steel |
Insulation |
heatshrunk polylefin sleeve |
|
Washer Head |
Material |
galvanized steel |
Under head insulation |
paper |
|
Thickness |
0.4mm (28 ga.) |
TYPE |
SIZES |
||
A |
B |
C |
|
CHP1 |
30mm(1-3/16”) |
9.5mm to 300mm |
2.7mm(12ga) ,2.0mm(14ga) |
CHP2 |
38mm(1-1/2”) |
9.5mm to 300mm |
2.7mm(12ga) ,2.0mm(14ga) |
