Cheap Price 500 Ton Hydraulic Horizontal Tensile Universal Test Bench for Steel Chain Achor Wire Rope
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Port of Shipment:
Shenzhen
Main Markets:
North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe, Central America, Northern Europe, Southern Europe, South Asia, Domestic Market
Location:
Shenzhen, Guangdong, China
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Tensile Testing Machine Horizontal Tensile Testing Machine Tensile Testing Machine Electronic Tensile Testing MachineUS$ 1 - 9.9MOQ: 1 Set -
Max Load 5000N Digital Automatic Woven Bag Tensile Breaking Force Testing MachineNegotiableMOQ: 1
-
Lab Application Examination Gloves Tensile Strength Testing EquipmentNegotiableMOQ: 1
-
Gold Brand Single Column Rubber Tensile Testing Machine PriceNegotiableMOQ: 1
-
10ton Gotech Ultimate Digital Display Dual Column Universal Tensile Bending Testing MachineNegotiableMOQ: 1
Product Description
Product name |
Chain Horizontal Universal Testing Machine |
Packing |
Wooden box |
Supply Capacity |
1 units/month |
Origin |
Shandong China |
Main parameters：
* Maximum test force: 5000KN;
* Force test range: 100kN ~ 5000KN;
* Class: ± 1%;
* Maximum tensile space : 10000mm;
* Test space adjustment spacing: 500mm;
* Net width of stretching space: 1000mm;
* Maximum stroke of piston: 800mm;
* Depth below centre : 800 mm (approx.)；
* Displacement resolution: 0.01mm;
* Maximum speed of piston : 100 mm / min;
* The overall dimension of the main engine is about 18000mm × 1500mm × 1200mm;
* Total weight: 35000kg
* Force test range: 100kN ~ 5000KN;
* Class: ± 1%;
* Maximum tensile space : 10000mm;
* Test space adjustment spacing: 500mm;
* Net width of stretching space: 1000mm;
* Maximum stroke of piston: 800mm;
* Depth below centre : 800 mm (approx.)；
* Displacement resolution: 0.01mm;
* Maximum speed of piston : 100 mm / min;
* The overall dimension of the main engine is about 18000mm × 1500mm × 1200mm;
* Total weight: 35000kg
Company Profile
Jinan Time Shijin Testing Machine Co., Ltd.
Jinan Time Shijin Testing Machine Co., Ltd. is a high-tech enterprise, It was established in 1952 as a state owned company, The earlist and most influential testing machine manufacturer in China. In 2003,We were associated with Beijing Time Group a public company.We have one national enterprise technology center, 108 many kinds of patents, ISO 9001 certificate, CE certificate, 131 units of precision CNC processing machine. we are China's famous brand, Quality trustworthy enterprise. And we also have the most professional sales and service team. We are not only famous in China, but also have been exporting into more than 35 oversea countries and areas.
Certifications
Packaging & Shipping
FAQ
Q1: Can I get some samples?
A: Yes, sample order is available for quality check and market test. But you have to pay the sample cost and express cost.
Q2: Do you receive customized order?
A: Yes, ODM & OEM are welcomed.
Q3: What's the lead time？
A: According to the order quantity, small order usually need 3-5 days, big order need negotiation.
Q4: What's your warranty terms?
A: We supply 12 months warranty time.
Q5: What's your payment terms?
A: We receive Escrow, T/T, West Union, Cash and etc.
