High Performance Toilet Paper Roll Packing Machine photo-1
High Performance Toilet Paper Roll Packing Machine photo-2
High Performance Toilet Paper Roll Packing Machine photo-3
High Performance Toilet Paper Roll Packing Machine photo-4
High Performance Toilet Paper Roll Packing Machine photo-5
Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Port of Shipment:
Shenzhen
Main Markets:
North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe, Central America, Northern Europe, Southern Europe, South Asia, Domestic Market
Location:
Shenzhen, Guangdong, China
Contact Supplier Request Quote Chat Now
Shenzhen Ruicheng Technology Co., Ltd.
Verified Business License
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Product Overview

XY-AI-398A High Performance Toilet Paper Roll Packing Machine

Outline
This machine is specially used for packaging toilet paper roll, with a conveyor belt. The machine to adapt to the toilet paper roll diameter is less than or equal to 90-120mm, 8-12 rolls of toilet paper. The machine is simple, flexible, sealed bag is the one machine. It’s easy to operate: Insert the pre-made bag into output hole, press the jog switch, it will automatically put toilet rolls into bag, meanwhile cutting and sealing.

Video Link: https://youtu.be/kNxiLQJF06s
Function & Features
1.Multi function: automatic conveying, single head operation, automatic feeding, automatic sealing, automatic countering.
2.Adopting the advanced PLC computer programming control and employing the liquid crystal text to display parameters, it is with simple set and water cooling control. Moreover, its temperature controlling is more precise so that heating wires and tapes with more stability can be protected more efficient. The machine use the servo motor to push the products to the bags, it causes to locating the products more accurately.
3.Packing and sealing are pretty and tidy. The machine can be operated with full-automation and semi-automation. The machine with conveyor can be connected with automatic toilet roll packing machine with conveyor. This allows the machine have high capacity and therefore to save the labor and reduce production cost.
4. Capacity: 8-12 bundling bag/min, 1 labor only to pack.
5. Suitable for core or coreless toilet roll. The machine cannot proofread color code automatically.
6. Comprehensive design, rigid frame, and imported major component, this allows our machine work steadily and efficiently, and therefore this makes our machine have long life.
Details Images
Finished Products
Product Paramenters
Speed
5-8 bags/min
Power
3KW 380V 50HZ 3phases
Sealing Transformer Power
0.45KW
Air Pressure
0.4-0.5 MPA
Overall Dimension
8700*1000*1300 mm
Weight
600-2000KG
