Newest Automatic Box Drawing Facial Tissue Paper Making Machine

Newest Automatic Box Drawing Facial Tissue Paper Making Machine photo-1
Newest Automatic Box Drawing Facial Tissue Paper Making Machine photo-2
Newest Automatic Box Drawing Facial Tissue Paper Making Machine photo-3
Newest Automatic Box Drawing Facial Tissue Paper Making Machine photo-4
Newest Automatic Box Drawing Facial Tissue Paper Making Machine photo-5
Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Port of Shipment:
Shenzhen
Main Markets:
North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe, Central America, Northern Europe, Southern Europe, South Asia, Domestic Market
Location:
Shenzhen, Guangdong, China
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Product Description

Newest Automatic Box drawing Facial Tissue Paper Making Machine

XY-GU-A-E Facial tissue production line, this Automatic Box Drawing Facial Tissue Machine Type tissue paper production line composed of one set of XY-GU-20A full-automatic box-drawing facial tissue machine,one set of XY-TN-125  or XY-TN-115Semi-automatic cardboard sealing machine and convey belt.

XY-GU-A-E Facial tissue production line gather embossment, folding, counting ,match with high-speed paper cutting machine, convey, automatic boxed and automatic sealing box in one body. This equipment adopt PLC, frequency control and equip with touch type multi-picture man and computer interface operation system. Adopt synchronization belt driving, speed-change machine driving for complete machine, which make the machine can suitable for various kind of raw material’s requirement , and improve the quality and efficiency. The operation flow of this production line is easy, high production efficiency and made perfect production. This production reduce the production operation and packaging person which save the expense of production and management.


1. Jumbo roll stands: 2, with pneumatic type wide belt to convey paper,each jumbo roll has independent tension adjustor and left-right adjusting device.
2. Pneumatic lifting jumbo roll to reduce the labor strength.
3. Auto stop when paper breaks to decrease the waste of paper.
4. Can fold different width of finished products : flexible vertical cutting device can adjust the cutting width between 100-210mm freely.
5. Can equip with embossing unit and edge embossing unit.
6. Roots vacuum bump absorbing system with strong suction,negative pressure is stable.

The production process is:

 Unreeling — Embossing—Folding —Cutting—Outputing—Transfering—Packing

Product Name
Automatic facial tissue machine Box drawing Facial Tissue Paper Making Machine
Model
XY-GU-A-E
Output lines
2-10lines
Speed
2000pcs--10000 pcs per min
Sizes of the proudct
Unfolding size 200x200, folding size 100x200mm(according to the customer's order)
Embossing device
Steel to rubber roller,Full embossing or edge emboss(Independent pneumatic type)
Driving system
Frequency inverter to adjust speed
Used power
7.5+15kw,380V,50/60HZ
Products Show
Packing & Delivery

Packing Details : Packing, standard export wooden case

Delivery Details : 30-90 days after order

Our Certifications

Best machine,Best service.

1.Xinyun's machines all have passed international certifications, like Soncap, CE and others.
2.The products we supply are at reasonable prices and in good condition and quality, and we provide supreme good after-services,including installation and training and so on.
3.We have sold many machines to over 50 countries,like the Middle East, Southern Asia, Africa, South America and East Europe. We also have won great comment from our old clients.

Our Company
FAQ

Q: Are you trading company or manufacturer ?

A: We are factory.

Q: How long is your delivery time?

A: Generally it is 5-10 days if the goods are in stock. or it is 45-70 days if the goods are not in stock, it is according to quantity.

Q: Do you provide samples ? is it free or extra ?

A: Yes, we could offer the sample for free charge but do not pay the cost of freight.

Q: What is your terms of payment ?

A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
