Help CenterC Type Connect Shackle, C-type Fast Shackle
Related Products
-
Grade 2 Kenter Shackle for Marine Anchor ChainUS$ 44 - 1800MOQ: 1 Piece -
ABS 66mm Kenter Shackle For Anchor Chain UseUS$ 40 - 1800MOQ: 1 Piece
-
Marine Boat Joining Kenter Shackle For Anchor Chain UseUS$ 49 - 1800MOQ: 1 Piece
-
Marine Mooring Stud Link Kenter for Anchor ChainUS$ 49 - 1800MOQ: 1 Piece
-
Black Painted Grade 2 Grade 3 Marine Kenter Shackle in StockUS$ 58 - 1800MOQ: 1 Piece
| Item No. | (mm) SWL(t) | ID | d | Dimensions (mm) | (Kg) Weight | ||||
| L | B | H | A | C | |||||
| QC11O9 | 10 | 9 | 29 | 174 | 116 | 44 | 34 | 37 | 3 |
| QC11O10 | 12.5 | 10 | 32 | 192 | 128 | 48 | 37 | 41 | 4 |
| QC11O11 | 14 | 11 | 35 | 210 | 140 | 53 | 40 | 44 | 6 |
| QC11O12 | 16 | 12 | 38 | 228 | 152 | 57 | 43 | 46 | 7 |
| QC11O13 | 21 | 13 | 41 | 246 | 164 | 62 | 46 | 51 | 9 |
| QC11O14 | 25 | 14 | 44 | 264 | 176 | 68 | so | 54 | 12 |
| QC11O15 | 32 | 15 | 47 | 282 | 188 | 71 | 52 | 58 | 14 |
| QC11O16 | 45 | 17 | 56 | 3J4 | 220 | 84 | 66 | 68 | 23 |
the C shape fast shackles (fast connection rings) series developed by our company: specification 6.3 t ≤ 45 t, alloy steel die forging, ultrasonic testing of forgings grade I qualified, Quenching and tempering hardness: the safety factor of HB350-380, is 4 times, which is mainly characterized by locking the tuxedo slot at both ends in its structure, which makes up for the phenomenon that the cable buckle is easy to fall off in the traditional structure. It is widely used in the rapid replacement of grab, hook, crane and so on because of rapid disassembly. Pear rope sleeve / quick release buckle can be used to increase the lifting height through a wide slot pulley. The connection mode is generally used in combination of cable joint C type fast shackle high strength shackle guard sleeve high strength lifting chain and so on.
