Home > Packaging & Printing > Packing Machinery > Filling Machine > KV Automatic Pouch Packaging Machine Irregular Sachet Snack Food Coffee Tea Ferment Powder Packing Machine
KV Automatic Pouch Packaging Machine Irregular Sachet Snack Food Coffee Tea Ferment Powder Packing Machine
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Port of Shipment:
Shenzhen
Main Markets:
North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe, Central America, Northern Europe, Southern Europe, South Asia, Domestic Market
Location:
Shenzhen, Guangdong, China
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Kingvictor Irregular Shape Sachet Stick Bag Packing MachineNegotiableMOQ: 1 -
Kingvictor Irregular Shaped Sachet Hand Sanitizer Gel Pouch Packing Sealing MachineNegotiableMOQ: 1
-
Kingvictor Irregular Shape Sachet Fruit Jelly Bag Packing MachineNegotiableMOQ: 1
-
Tomato Ketchup Filling Packing Packaging Machine for SaleNegotiableMOQ: 1
-
BG Vertical Automatic Tomato Paste / Ketchup Pouch Liquid Filling MachineNegotiableMOQ: 1
Foshan KingVictor Machinery Co. Ltd
Factory area:11,000M² Employees:300
certificates:CE SGS Founded in:2004
photo of machine
Irregular Shaped Sachet Packaging Machine
Suitable for packaging laundry liquid, soy sauce, vinegar, milk, mineral water, edible oil, fruit juice, carbonated beverage,chemical liquid, liquid pesticide, insecticide, etc.
Pump filler is made of 304 stainless steel for food contacting.
The filling capacity of pump filler is adjustable for measuring different volume of products by adjust the valve opening and closing time ;
This pump filler is availible for liquid, such as water, oil, liquid milk, tomato paste, honey and other kind of sauce.
The machine's operating instructions are programmed into the PLC controller,and then we can easily set parameters and control the machine on the touchscreen.the machine is equipped with frequency converter to adjust machine running speed at will;
PID temperature controller to control the sealing temperature accurately;
Fault-self diagnosis function can display the machine fault on touch screen for quick
troubleshooting.
The machine can make the plastic film into bags, which saves at least 30% package cost instead of buying pre-made bags;
Date printer is available to be equipped on this machine for printing production date on bags;
The position of the bag cut can be according to position of the color code detected.
The temperature of the horizontal and vertical sealing controlled separately, which can ensure sealing tightly for different material's thickness.
Package material feeding driven by Inverter motor, which can run stable to make a beautiful sachets and the running speed can be adjust at will.
Product Parameter
Model | KV-100YYS | |
Packaging speed | 10-70bags/min | |
Bag width range | Max 100mm | |
Bag length range | Max.180mm | |
Package material width | Max.220mm | |
Power Specifications | 220V 50/60Hz | |
Equipment power | 1.2kw |
Packing products
successful case
package types
stick sachet
back seal
gusset bag
3 side sealing sachet
4 side sealing sachet
Zipper bag
Labeling
Linking bag
Punch hook
Want to know more,please contact us
Our factory
Large vertical packing machine workshop
Horizontal packing machine workshop
Small vertical packing machine workshop
Film production workshop
Design department
Sales department
After-sales Service
Foshan Kingvictor Machinery Co., Ltd, plant area of over 11,000 square meters, respectively, the production of various kinds of packing machine.Sales department has more than 15 years experience in aftermarket master 26 people, responsible for domestic and international sale equipment installation and commissioning, operator training and technical maintenance.
Packing & Delivery
We wrap the machine in film ,put it Into the wooden box.
And put the machine in the lorry,then transport to the port or airport.
Want to know more,please contact us
Our Customers
Customers from Saudi Arabia.
Customers from Germany.
Customers from Spain.
Customers from Nigeria.
Customers from America
Customers from Turkey
After sales service
1.Providing professional installation instructions and video of troubleshoot.
2.Providing machine control software updates and operation teaching in our factory.
3.Two years free maintenance for touch screen,inverter,PLC, temperature controler,photoelectric sensor with freight prepaid.
4.Engineers available to service the machinery overseas, buyers pay 100 US dollars daily service fees and travel expenses.
5.Pick-up services at BAIYUN airport, providing packaging solutions and testing material on machines, full refund if unsatisfied with the machine.
Certifications
ISO9001,ISO14001,ISO22000
OHSAS18001,BSCI,SA8000
CE,SGS
