stainless steel copper brass silver gold 20w fiber jewelry ring rotary laser marking engraving machine for metal in Germany
Application:
1).Materials:
Metals ( Gold, silver, copper, alloy, aluminum, steel, stainless steel, name card )
Non-metal ( Plastic: engineering plastic and hard plastic, etc. Used in electronic components integrated circuits, mobile communications, precision instruments, glasses watch and clocks, computer keyboard, accessories, auto parts, plastic buttons, plumbing fittings, sanitary ware, PVC pipe, medical equipment, packaging bottles, etc.)
2).Industry:
Jewellery, Keyboards of cell phone, Auto parts, Electronic components, Electronic appliance, Communication apparatus, sanitary wares, buckles, kitchenware, Sanitary equipment’s, Hardware tools, Knife, Glasses, Clock, Cooker, Stainless steel products etc.
Marking sample:
Characture:
1) High precision marking, swift, engraving depth controllable.
2) Applied on most of non-metal material.
3) Excellent beam quality, high photoelectric conversion efficiency, good performance and can be competent at fine processing.
4) Windows interface adopted, compatible with CORELDRAW, AUTOCAD, PHOTOSHOP, etc.
5) Support PLT,PCX, DXF,BMP and other formats, execute SHX, TTF font directly, support automatic code, serial number, batch number, two-dimensional bar code marking, and garphic anti marking function available.
Technology Parameter:
|
Technical parameter |
|
|
Item / Model |
LXF-20/30/50/60/70/100/120W |
|
Laser source |
Domestic Raycus(Germany IPG/China CAS/MAX/JPT Mopa color marking for optional) |
|
Laser power |
20w, 30w, 50w,60w ,70w,100,120w |
|
Laser type |
Fiber laser |
|
Graphic Format Supported |
DXF,PLT,BMP,JPG,PNG,TIP,PCX,TGA,ICO, |
|
Marking speed |
≤8000mm/S |
|
Max.Marking Depth |
≤0.4mm |
|
Laser Wavelength |
1064nm |
|
Marking lines |
0.06-0.1mm |
|
Minimum line width |
0.06mm |
|
Minimum character |
0.15mm |
|
Resolution ratio |
0.01mm |
|
Graphic format supported |
BMP, PLT, DST, DXF, AI |
|
Software supported |
TAJIMA, CorelDraw, Photoshop, AutoCAD |
|
Equipment Dimensions |
71*50*73cm(different model has different size,detailed can be confirmed with sellers) |
|
Net Weight: |
80kg(different configuration has small difference) |
|
Unit Power |
≤500W |
|
Optional Spare Parts |
Rotary/Protection glasses/outside red light/night light and other optional customized parts and so on. |
Contact us for more information
Q1 :How about warranty?
A1:3 years quality guaranty, the machine with main parts(excluding the consumables) shall be changed free of charge(some parts will be maintained) when if any problem during the warranty period.
Q2:2 I don’t know which one is suitable for me ?
A2:Please tell me your
1) Max work size:We can do work size with 110*100mm-----300mm*300mm.
2) Materials and marking effect:we will check whether our machine is suitable for you or not and choose a most suitable power and optional parts.
Q3:Payment terms?
A3:Alibaba trade assurance/TT/West Union/Payple/LC/Cash and so on.
Q4:Do you have CE document and other documents for customs clearance?
A4:Yes,we have Original. At first we will show you and And after shipment we will give you CE/Packing list/Commercial Invoice/Sales contract for customs clearance.
Q5:I don’t know how to use after i receive Or i have problem during use,how to do?
A5:
1) We have detailed user manual with pictures and CD,you can learn step by step.And our user manual update every month for your easy learning if there is any update on machine.
2) If have any problem during use,you need our technician to judge
The problem elsewhere will be solved by us. We can provide team viewer
/Whatsapp/Email/Phone/Skype with cam till all of your problems finished.We can also provide Door service if you need.
Q6:Delivery time
A5:General configuration:3 days. Customized:7-10 working days.
