memory card making machine portable mini mopa fiber laser marking machine
Application: 1).Materials:
Metals ( Gold, silver, copper, alloy, aluminum, steel, stainless steel, name card )
Non-metal ( Plastic: engineering plastic and hard plastic, etc. Used in electronic components integrated circuits, mobile communications, precision instruments, glasses watch and clocks, computer keyboard, accessories, auto parts, plastic buttons, plumbing fittings, sanitary ware, PVC pipe, medical equipment, packaging bottles, etc.)
2).Industry:Jewellery, Keyboards of cell phone, Auto parts, Electronic components, Electronic appliance, Communication apparatus, sanitary wares, buckles, kitchenware, Sanitary equipment’s, Hardware tools, Knife, Glasses, Clock, Cooker, Stainless steel products etc.
Marking sample:
Characture:
1).Long lifetime, over 100,000 hours.
2).Compact laser source with air cooling.
3).2 to 5 times more productive a traditional laser marker or laser engraver.
4).Super quality galvanometer scanning system.
5).High accuracy and repeatability for correct marks each time with galvanometer scanners and electronic controls.
6).More stable performance.
7).Professional control board and marking software. The software controlling system has the interface of windows and comprises files output by software such as Coreldraw, AutoCAD, Photoshop etc. It can support various file formats such as PLT,DXF,PCX,BMP etc.
8).Output power is stable, optical mode is good, beam quality is excellent.
9).Marking speed is fast, efficient, and high accuracy.
10).Appearance is professional, operation is easy.
Optional Parts:
Technology Parameter:
|
Technical parameter |
|
|
Item / Model |
LXFP-20/30/50/60/70/100/120W |
|
Laser source |
Domestic Raycus(Germany IPG/China CAS/MAX/JPT Mopa color marking for optional) |
|
Laser power |
20w, 30w, 50w,60w ,70w,100,120w |
|
Laser type |
Fiber laser |
|
Graphic Format Supported |
DXF,PLT,BMP,JPG,PNG,TIP,PCX,TGA,ICO, |
|
Marking speed |
≤8000mm/S |
|
Max.Marking Depth |
≤0.4mm |
|
Laser Wavelength |
1064nm |
|
Marking lines |
0.06-0.1mm |
|
Minimum line width |
0.06mm |
|
Minimum character |
0.15mm |
|
Resolution ratio |
0.01mm |
|
Graphic format supported |
BMP, PLT, DST, DXF, AI |
|
Software supported |
TAJIMA, CorelDraw, Photoshop, AutoCAD |
|
Equipment Dimensions |
760*680*770mm(different model has different size,detailed can be confirmed with sellers) |
|
Net Weight: |
70/80kg(different configuration has small difference) |
|
Unit Power |
≤500W |
|
Optional Spare Parts |
Rotary/Protection glasses/outside red light/night light and other optional customized parts and so on. |
