Best service Fiber laser metal cutting machine 2000w Raycus laser power
| FEATURES |
|
1.Stable and reliable light path system and control system. 2.Imported original fiber laser generator with great and stable performance to ensure the lifespan over 100,000 hours. 3.High cutting quality and efficiency with smooth cutting edge.The cutting speed up to 100m/min. 4.Full protection cover to ensure operator safety and reduce factory air pollution. 5.Dual and exchange work table to save uploading time. 6.The dual gear and driver system to ensure high work precision. Imported guide rail and ball screw to guarantee machine stable work process. |
| PRODUCT PARAMETERS |
| Material | Thickness | Speed(m/min) | Air pressure(MPA) | Gas | Cutting height |
| Stainless Steel | 0.5 | >24 | 1 | N2 | 0.6 |
| 1 | 17~21 | >1.1 | N2 | 0.6 | |
| 2 | 5.4~7.2 | >1.5 | N2 | 0.6 | |
| 3 | 2.1~3 | >2.0 | N2 | 0.6 | |
| 4 | 0.8~1.5 | >2.0 | N2 | 0.6 | |
| 5 | 0.6~0.9 | >2.0 | N2 | 0.6 | |
| 1 | 15~18 | 1 | O2 | 1 | |
| 2 | 5.1~6 | 0.5~0.8 | O2 | 1 | |
| 3 | 3.5~4.2 | 0.25~0.4 | O2 | 1 | |
| Carbon Steel | 4 | 2.3~2.7 | 0.15~0.2 | O2 | 1 |
| 5 | 1.7~2.1 | 0.15~0.2 | O2 | 1 | |
| 6 | 1.2~1.8 | 0.10~0.15 | O2 | 1 | |
| 8 | 0.9~1.1 | 0.10~0.15 | O2 | 1 | |
| 10 | 0.6~0.72 | 0.10~0.15 | O2 | 1 |
| PARAMETER |
| Model | TPF-4020 |
| Working Area |
4000*2000mm |
| Laser Power | 1000W |
| Laser Wavelength | 1060nm-1080nm |
| Cutting Speed | 100m/min |
| Gross Power | 20KW-30KW |
| Max Velocity of Movement | 140m/min |
| Machine Size | 8500*2850*2500mm |
| Water chiller | Special water chiller for fiber laser generator |
| Laser head | High accuracy professional fiber laser head |
| Driving system | High-speed servo motor |
| Electric components | Omron, Scheider |
| Proportional valve | Japanese SMC |
| How much does a laser cutting machine cost? |
|
Different model has different body structure and also different laser power source, the high-level machine with more strong body-structure and more perfect spare parts and long-life use. We advise customer choose fiber laser machine to depend on your practical need to choose the machine price. Following spare parts can be replaced based on your need. |
| MACHINE APPLICATION |
|
Fiber laser Cutting Machine meets the parts processing requirements of most industries, working accuracy is stable. At present, laser cutting machines have been widely used in electronics, electrical, mechanical hardware, new energy lithium, packaging, solar, LED, automotive, and other industries.
This machine is mainly applicable to stainless steel, carbon steel, manganese steel, galvanized sheet, a variety of alloy plates, silicon steel, titanium plate, and other metal material cutting. |
| FIBER LASER CUTTING MACHINE COMPANY |
| Shenzhen Tip-top Manufacture & Trading Co., Ltd is a professional company located in the beautiful city of Jinan, Shandong province. which specializes in the manufacture and development of CNC machinery as well as the sales of domestic and foreign and technical services. it is engaged in the research, development, production, and service of Laser engraving and cutting machine, Fiber laser marking machine and laser welding machine have CE Certificate and international certification industrial, High precision, low energy consumption, automatic processing, little environmental pollution and make our products more and more industries played an important role. |
| SHIPPING |
|
1.Timely delivery. Each machine is arranged with precise assembly steps without any delay. 3.Whole film packaging machine; anti-collision package edge; fumigation-free plywood wooden box and pallets with an iron binding belt. |
| COMPANY SERVICES |
|
(1) Two year quality guaranty, the machine with main parts(excluding the consumables)shall be changed free of charge when if any problem during the warranty period. (2) Lifetime maintenance free of charge. (3) Free training course at our plant. (4) 18 hours on line service each day, free technical support. (5) Machine has been adjusted before delivery.We will take machine photos and make machine working image for you ,after gettingyour agreement ,then we will book a ship. (6) Providing technical services to the door(We have professional engineers to offer machine installation commissioning and maintenance). (7) If you have any problem during your use.you need our technician to judge where the problem is and help you to solve it. We can provide team viewer and skype with cam till all of your problems solved. |
| FAQ |
|
1.Q: Why should we choose you? A: If you choose us, you will get top quality, best service, reasonable price, and reliable warranty.
2.Q: I'm not familiar with the machine, how to choose?
3.Q: How to operate the machine?
4.Q: Can I get the sample to check the quality of the machine?
5.Q: Can the machine be customized according to my requirements?
6.Q: Can you arrange the shipment for us? If you are interested in our products, please contact me, I will serve you! |
