ISO9001 Quickly Build Light Prefabricated Steel Structure Fabrication
Negotiable
MOQ: 25 Tons (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
GUANGLEI
Place of Origin:
China
Model Number:
GLWH-01
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
New Design Reliable Seismic Earthquake Prefabricated Light Steel Structure Muti Slope WorkshopNegotiableMOQ: 25 Tons -
Wind-resistant Prefabricated Steel Structure WarehouseNegotiableMOQ: 25 Tons
-
Prefab Steel Structure Space Frame Light Steel Coal StorageNegotiableMOQ: 25 Tons
-
Prefab Steel Structure Space Frame Light Steel Coal Storage Grid Steel StructureNegotiableMOQ: 25 Tons
-
Seismic Earthquake Prefabricated Light Steel Structure Muti Slope WorkshopNegotiableMOQ: 25 Tons
Brand Name
GUANGLEI
Place of Origin
China
Model Number
GLWH-01
Type
Light
Application
Steel Workshop
Standard
GB
Grade
Q235, Q355
Dimensions
Accordinng to client's requirements
Specifications:
1) Main Steel: Q345, Q235, Q345B, Q235B etc.
2) Column & Beam: Welded or Hot rolled H-section
3) Connection method of steel structure: welding connection or bolt connection
4) Wall & Roof: EPS, Rockwool, PU sandwich, corrugated steel sheet
5) Door: Rolled up door or Sliding door
6) Window: Plastic steel or Aluminum alloy window
7) Surface: Hot dip galvanized or painted
8) Crane: 5MT, 10MT, 15MT and more
Drawings & Quotation:
1) Customized design is welcomed.
2) In order to give you an exactly quotation and drawings, please let us know length, width, eave height
and local weather. We will quote for you promptly.
and local weather. We will quote for you promptly.
Brief Description
Pre engineered steel structure building is a Green economy building system, which is formed by the main
structure (H-section steel for beam/column, C channel steel or Z channel steel for purlin), substructure
(Round steel bar or Angle steel for bracing, Round steel tube for tie bar, Angle steel for angle brace), roof
and wall system (using sandwich panel or single steel sheet), door and window system. Pre engineered steel
structure building building is widely used as warehouse, workshop, hangar, shed, etc..
structure (H-section steel for beam/column, C channel steel or Z channel steel for purlin), substructure
(Round steel bar or Angle steel for bracing, Round steel tube for tie bar, Angle steel for angle brace), roof
and wall system (using sandwich panel or single steel sheet), door and window system. Pre engineered steel
structure building building is widely used as warehouse, workshop, hangar, shed, etc..
Product Description
| Product description |
| Items | Specification | |
| Main Steel Frame | Column | Q235, Q345 Welded H Section Steel |
| Beam | Q235, Q345 Welded H Section Steel | |
| Secondary Frame | Purlin | Q235 C and Z purlin |
| Knee brace | Q235 Angle Steel | |
| Tie rod | Q235 Circular Steel Pipe | |
| Brace | Q235 Round Bar | |
| Vertical&Horizontal support | Q235 Angle Steel, Round Bar or Steel Pipe | |
| Maintenance system | Roof panel | EPS Sandwich Panel / Glass Fiber Sandwich Panel / |
| Rock Wool Sandwich Panel / Pu Sandwich Panel /Steel Sheet | ||
| Wall panel | Sandwich Panel / Corrugated Steel Sheet | |
| Accessories | Window | Aluminiumn Alloy Window / PVC Window / Sandwich Panel Window |
| Door | Sliding Sandwich Panel Door / Rolling Metal Door / Personal Door | |
| Rainspout | PVC | |
| Live load on Roof | In 120kg/Sqm (Color steel panel surrounded) | |
| Wind Resistance Grade | 12 Grades | |
| Earthquake-resistance | 8 Grades | |
| Structure Usage | Up to 50 years | |
| Finishing Options | Vast array of colors and textures available | |
| Paint Options | Alkyd paiting, two primary painting, two finish painting | |
| (gray paint, red paint, white paint, epoxy zinc etc.) Or Galvanized. | ||
