MJ/40.5 t Container Gantry Crane

MJ track type CONTAINER GANTRY CRANE SPECIFICATION MODEL:

Container Crane Model: Mj, MGJ; general rated lifting capacity: 35 tons, 40.5 tons and other specifications; General Span: 25 meters, 29 meters, 30 meters, 35 meters, 40 meters and other specifications; Commonly used lifting height: three-over-four, four-over-five and other specifications; working level: A6A7 and so on; MJ track type Container Gantry Crane is a semi-custom machine, according to your site conditions and needs to determine the track size and other parameters of non-calibration Crane.

MJ track type CONTAINER GANTRY CRANE SPECIFICATION MODEL:

Container Crane Model: Mj, MGJ;

General rated lifting capacity: 35 tons, 40.5 tons and other specifications;

General Span: 25 meters, 29 meters, 30 meters, 35 meters, 40 meters and other specifications;

Commonly used lifting height: three-over-four, four-over-five grade;

 working level: a6/a7 Grade;

MJ track type Container Gantry Crane is a semi-custom machine, according to your site conditions and needs to determine the track size and other parameters of non-calibration Crane.

MJ TRACK CONTAINER GANTRY CRANE SCOPE OF APPLICATION:

Track type Container Gantry Crane can be used without cantilever according to the use of the site, but also can increase the use of single cantilever and double cantilever; winch trolley can be upper trolley rotation and lower container crane rotation. The rail type Container Gantry Crane is mainly used for unloading, handling and stacking of containers in Railway Transfer Yard, Port Wharf and large container storage yard, and can load and unload 20', 40'and 45'international standard containers.

Standard Specification for MJ TRACK CONTAINER GANTRY CRANE:

Crane Design Specification: SAFETY CODE FOR LIFTING APPLIANCES: GB 6067.1-2010

rail type Container Gantry Crane: GB T19683-2005

 quality inspection and assessment standards for port equipment engineering: JT T244-2008

 rail type Container Gantry Crane Safety Code: jt566-2004

 bridge and Gantry crane manufacturing and rail installation tolerances: GB T10183-1988
