200W 3500mA 28-56VDC Constant Current Waterproof LED Driver SELV CLASS 2 Transformer

200W 3500mA 28-56VDC Constant Current Waterproof LED Driver SELV CLASS 2 Transformer thumbnail-1
200W 3500mA 28-56VDC Constant Current Waterproof LED Driver SELV CLASS 2 Transformer thumbnail-2
200W 3500mA 28-56VDC Constant Current Waterproof LED Driver SELV CLASS 2 Transformer thumbnail-3
200W 3500mA 28-56VDC Constant Current Waterproof LED Driver SELV CLASS 2 Transformer thumbnail-4
200W 3500mA 28-56VDC Constant Current Waterproof LED Driver SELV CLASS 2 Transformer photo-1
200W 3500mA 28-56VDC Constant Current Waterproof LED Driver SELV CLASS 2 Transformer photo-2
200W 3500mA 28-56VDC Constant Current Waterproof LED Driver SELV CLASS 2 Transformer photo-3
200W 3500mA 28-56VDC Constant Current Waterproof LED Driver SELV CLASS 2 Transformer photo-4
US$ 12 - 14 MOQ: 500 Pieces
Key Specifications
Get Latest Price
Brand Name:
AMCFLEX
Place of Origin:
China
Model Number:
APV-200C-3500
Contact Supplier Request Quote Chat Now
Changzhou AMCFLEX Technology Co Ltd
Verified Business License
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
20 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name AMCFLEX
Place of Origin China
Model Number APV-200C-3500
Output Power 101 - 200W
Output Type Single
Output Current 3500mA
Output Frequency 50/60hz
Output Voltage 28-56VDC
Input Voltage 220V

Model: APV-200C-3500

Constant voltage LED Power Supply.

Input Voltage: 200-240VAC 47-63Hz

Output Voltage: 28-56VDC

Output Current: 3500mA

Output Rated Power: 200W max

Inrush Current: 70 Amps max. at 230VAC/50Hz,full load

No Load Power Consumption: ＜0.5W

Protections: Short Circuit /Over Current /Over Voltage

/over temperature protection

Short Circuit Protection (SCP) Yes,hiccup mode, auto-recovery

Over Voltage Protection (OVP): Yes,hiccup mode, auto-recovery

Over Current Protection (OCP): Yes,hiccup mode, auto-recovery

Working TEMP.: -30°C-70°C

Working Humidity: 10%-90% RH non-condensing

Storage TEMP.,Humidity and altitude: -40℃ ~+70°C ambient

temperature and a 5% to 95% relative humidity range throughout

an altitude range of -60 meters to +5000 meters AMSL.

Certificates and approvals: CE CB SELV ROHS

MTBF: 100Khours minimum at full load at 25℃ ambient

Dimension: 205 x 70 x 45mm (L x W x H)

Packing: 1.2kg; 15pcs./ctn; ctn weight and dimensions: 18.5kg;

45.5 x 29.5 x 19cm


Product Tags: Waterproof LED Driver , Constant current led driver , 200W 1050mA LED Driver , Current LED Strip , Plastic housing LED driver
