Help CenterOffer 013.32.1405 Four Point Contact Ball Slewing Bearing With Internal Gear 1525X1235X119mm
Related Products
-
061.25.1120.301.11.1523 Four Point Contact Ball Slewing Bearing With External Gear 1013X1278X79mmUS$ 200 - 1000MOQ: 4 Pieces -
Four Point Contact Ball Slewing/turntable Bearing 232.20.0600.503 With Size 948x734x56mmUS$ 200 - 1000MOQ: 4 Pieces
-
585DBS164Y Slewing Bearing 585x810x85mm Belong to Four Point Contact Ball Bearing With Internal TeethUS$ 200 - 1000MOQ: 4 Pieces
-
MTE-730 Four Point Contact Ball Slewing Bearing China Supplier 41.85x28.75x3.25 Inch SizeUS$ 200 - 1000MOQ: 4 Pieces
-
MTO-324T Belong to Four Point Contact Ball Slewing Bearing Without Teeth520.3x323.85x52.4mmUS$ 200 - 1000MOQ: 4 Pieces
offer 013.32.1405 four point contact ball slewing bearing with internal gear 1525X1235X119mm
China slewing Bearing supplier offer 013.32.1405 four point contact ball slewing bearing with internal gear ,1525X1235X119mm
How to choose the right slewing bearing type 013.32.1405 it will based on the following bearing data:
1. applied loads
2. Collective loads with respective time percentages
3. Speed or number of movements and angle per time unit together with the relating collective loads
4. Circumferential forces to be transmitted by the greasing
5. Bearing diameter
6. Other operating conditions
013.32.1405 slewing bearing parameter:
Bearing type |
013.32.1405 |
Boundary dimension |
1525x1235x119mm |
Outer dia: |
1525mm |
Inner dia: |
1235mm |
Height: |
119mm |
Teeth : |
Internal teeth |
No.of teeth |
90 |
Module |
14 |
Press angle |
20 degree |
The slewing bearing delivery time: about 40 days after getting the order
The material :50Mn or 42CrMo available
Package:standard strong wooden case,suiting for long shipping trip
013.32.1405 slewing ring feature:
Can support high dynamic loads,transmitting axial and radial forces simultaneously as well as the resulting tilting moments.
013.32.1405 slewing bearing application:
Hoisting,mechanical handle and general mechanical engineering etc.
Send Inquiry to This Supplier
