Cross-Roller Ring Series
With the Cross-Roller Ring, cylindrical rollers are arranged crosswise, with each roller perpendicular to the adjacent roller, in a 90゜ V groove, separated from each other by a spacer retainer. This design allows just one bearing to receive loads in all directions including, radial, axial and moment loads.Since the Cross-Roller Ring achieves high rigidity despite the minimum possible dimensions of the inner and outer rings.
Features
Compact, Highly Rigid Swivel Bearings ,Achieving a Superb Rotation Accuracy
| Bearing No. | Dimensions (mm) | Oil holes dOH (mm) |
Basic loading rates (kN) | Abutment and fillet (mm) | |||||
| Inner diameter (d) |
Outer diameter (D) | Width (B, T) |
Dynamic load, C |
Static load, C0 |
da | Da | ra (max) |
||
| CRBA 11020 | 110 | 160 | 20 | 2.5 | 42.7 | 70.2 | 126 | 143 | 1 |
| CRBA 12016 | 120 | 150 | 16 | 2.5 | 28.1 | 50.3 | 126 | 143 | 1 |
| CRBA 12020 | 120 | 170 | 20 | 2.5 | 44.9 | 76.9 | 136 | 153 | 1.5 |
| CRBA 12025 | 120 | 180 | 25 | 2.5 | 66.3 | 109 | 138 | 158 | 1.5 |
| CRBA 13025 | 130 | 190 | 25 | 2.5 | 67.8 | 114.8 | 148 | 168 | 1.5 |
| CRBA 14025 | 140 | 200 | 25 | 2.5 | 69.5 | 120.6 | 161 | 178 | 1.5 |
| CRBA 15025 | 150 | 210 | 25 | 2.5 | 73.1 | 131.9 | 168 | 188 | 1.5 |
| CRBA 15030 | 150 | 230 | 30 | 3 | 114.3 | 187.3 | 181 | 198 | 1.5 |
| CRBA 16025 | 160 | 220 | 25 | 2.5 | 74.5 | 137.7 | 181 | 198 | 1.5 |
| CRBA 17020 | 170 | 220 | 20 | 2.5 | 52.3 | 103.6 | 183 | 203 | 1.5 |
| CRBA 18025 | 180 | 240 | 25 | 2.5 | 79.6 | 154.8 | 198 | 218 | 1.5 |
| CRBA 19025 | 190 | 240 | 25 | 2.5 | 54.5 | 113.6 | 203 | 223 | 1 |
Drawings and other parameters ,pls contact us free, thanks
Market:
After years of development ,our products have been sent out to Germany ,Italy, Spain, Romania,Belgium,Israel,Russia,Korea,Mexico,India etc. Good quality and Service earn the constant supports from all our customers. any of your questions will be welcomed here any time.
Payment Terms:
Most of our customers use T/T( 40% in advance, Balance before shippment), Western Union ,Money Gram, for larger amount consider LC, all can be negotiable.
Many other precision bearings series available
