CP-8841-K9 Overview
The Cisco IP Phone 8841 integrates 5 inches high-resolution widescreen VGA backlit color display, localized language support to meet the needs of global users, the five programmable line keys can be configured to support multiple directory numbers and various calling features,the fixed function keys allow you one-touch access to applications, messaging, directory and conference.
- CP-8841-K9 Specification
-
CP-8841-K9 Specifications Audio codec support
● G.711a-law and mu-law, G.722, G.729a, Internet Low Bitrate Codec (iLBC), and Internet Speech Audio Codec (iSAC)
Call features
● + Dialing
● Abbreviated dialing
● Adjustable ring tones and volume levels
● Adjustable display brightness
● Agent greeting
● Auto-answer
● Auto-detection of headset
● cBarge
● Busy Lamp Field (BLF)
● Busy Lamp Field (BLF) Pickup
● Busy Lamp Field (BLF) speed dial
● Callback
● Call forward
● Call forward notification
● Call filter
● Call history lists
● Call park
● Call pickup
● Call timer
● Call waiting
● Call chaperone
● Caller ID
● Corporate directory
● Conference, including traditional Join feature
● Cross Cluster Extension Mobility (EMCC)
● Direct transfer
● Extension mobility
● Fast-dial service
● Forced access codes and client matter codes
● Group call pickup
● Hold
● Intercom
● Immediate divert
● Malicious-caller ID
● Message-waiting indicator (MWI)
● Meet-me conference
● Mobility
● Music on hold (MoH)
● Mute
● Network profiles (automatic)
● On- and off-network distinctive ringing
● Personal directory
● PickUp
● Predialing before sending
● Privacy
● Private Line Automated Ringdown (PLAR)
● Redial
● Ring tone per line appearance
● Service Uniform Resource Locator (URL)
● Shared line
● Silent monitoring and recording
● Speed dial
● Time and date display
● Transfer
● Uniform Resource Identifier (URI) dialing
● Visual voice mail
● Voice mail
● Whisper coaching
Electronic hookswitch
● You can control the hookswitch electronically with a third-party headset connected to the auxiliary port.
Quality-of-service (QoS) options
● The phone supports Cisco Discovery Protocol and 802.1Q/p standards, and can be configured with an 801.1Q VLAN header containing the VLAN ID overrides configured by the Admin VLAN ID.
Network features
● Session Initiation Protocol (SIP) for signaling
● Session Description Protocol (SDP)
● IPv4 and IPv6
● User Datagram Protocol (UDP) (used only for Real-Time Transport Protocol [RTP] streams)
● Dynamic Host Configuration Protocol (DHCP) client or static configuration
● Gratuitous Address Resolution Protocol (GARP)
● Domain Name System (DNS)
● Trivial File Transfer Protocol (TFTP)
● Secure Hypertext Transfer Protocol (HTTPS)
● VLAN
● Real-Time Transport Protocol (RTP)
● Real-Time Control Protocol (RTCP)
● Cisco Peer-to-Peer Distribution Protocol (PPDP)
● Cisco Discovery Protocol
● LLDP (including LLDP-MED)
● Switch speed auto-negotiation
Security features
● Secure boot
● Secure credential storage
● Device authentication
● Configuration file authentication and encryption
● Image authentication
● Random bit generation
● Hardware cryptographic acceleration
● Certificate Authority Proxy Function (CAPF)
● Manufacturer-Installed Certificates (MIC)
● Locally Significant Certificates (LSC)
● Ethernet 802.1x supplicant options: Extensible Authentication Protocol-Flexible Authentication via Secure Tunneling (EAP-FAST) and Extensible Authentication Protocol-Transport Layer Security (EAP-TLS)
● Signaling authentication and encryption using TLS
● Media authentication and encryption using SRTP
● HTTPS for client and server
● Secure Shell (SSH) Protocol server
● SSL-based VPN client
Physical dimensions
(H × W × D)● 9.02 x 10.13 x 1.57 in. (229.1 x 257.34 x 40 mm)
(excluding foot stand)Weight (with handset)
● 2.58 lb (1.17 kg)
Phone-casing composition
● Polycarbonate acrylonitrile butadiene styrene (ABS) textured plastic; Cosmetic class A
Operational temperature
● 32 to 104°F (0 to 40°C)
Nonoperational temperature shock
● 14 to 140°F (-10 to 60°C)
Humidity
● Operating 10 to 90%, noncondensing
● Nonoperating 10 to 95%, noncondensing
Language support
● Arabic (Arabic Area)
● Bulgarian (Bulgaria)
● Catalan (Spain)
● Chinese (China)
● Chinese (Hong Kong)
● Chinese (Taiwan)
● Croatian (Croatia)
● Czech (Czech Republic)
● Danish (Denmark)
● Dutch (Netherlands)
● English (United Kingdom)
● Estonian (Estonia)
● French (France)
● French (Canada)
● Finnish (Finland)
● German (Germany)
● Greek (Greece)
● Hebrew (Israel)
● Hungarian (Hungary)
● Italian (Italy)
● Japanese (Japan)
● Latvian (Latvia)
● Lithuanian (Lithuania)
● Korean (Korea Republic)
● Norwegian (Norway)
● Polish (Poland)
● Portuguese (Portugal)
● Portuguese (Brazil)
● Romanian (Romania)
● Russian (Russian Federation)
● Spanish (Columbia)
● Spanish (Spain)
● Slovak (Slovakia)
● Swedish (Sweden)
● Serbian (Republic of Serbia)
● Serbian (Republic of Montenegro)
● Slovenian (Slovenia)
● Thai (Thailand)
● Turkish (Turkey)
