Help CenterPack Fire Tester
Related Products
-
Pack Drop TesterUS$ 3,000 - 10,000MOQ: 1 Set -
Dry Oven Test ChamberUS$ 800 - 2,600MOQ: 1 Set
-
Laboratory Electronic Salt Spray Corrosion Testing ChamberUS$ 3,000 - 4,500MOQ: 1 Set
-
HPLC Gas Chromatograph (GLPC/GC) Mass Spectrometry Analysis MachineUS$ 5,800 - 22,000MOQ: 1 Set
-
Gas Chromatography Mass Spectrometry Test Machine(GLPC/GC)US$ 8,000 - 8,000MOQ: 1 Set
APPLICATION
Be able to complete external fire safety tests for various power batteries (including lead acid, nickel hydrogen, lithium ion, zinc air, super capacitor, etc.) for automobiles.
STANDRAD
Meet the requirements of GBT314673-2015, ECER100, GB18296-2018, ECER34 and other standard battery pack external fire test.
FEATURES
1. Combustion temperature: liquid or gaseous fuel is fired outside the battery pack. The battery pack is placed inside the flame with a flame temperature >1000 degrees
2. Battery bearing table size (W*D*H): 2500*1500*1200mm
3. Burning plate size (W*D*H): 3000*2200*2000mm (sample normal test)
4. The distance between the bearing plane and the combustion disc is 500mm;
5. Carrying weight: ≥2000kg
STANDARD parameters
|
Model |
HD-H209-1 |
|
|
Sample carrier |
External dimension |
3300*2200mm |
|
Carrying battery pack weight |
≤ 2T (can be customized load bearing) |
|
|
Indirect combustion layer |
External dimension |
3200*2100mm |
|
Number of refractory bricks |
260 pieces |
|
|
Refractory brick size |
240*120*70mm |
|
|
Fire cover size |
3500*2300mm |
|
|
Oil pan |
size |
3200*2000mm (customized size to meet different batteries) |
|
Burning area |
Adjustable |
|
|
Oil level and test battery pack bottom distance |
Adjustable, the default distance is 500mm |
|
|
Sport mode |
Manual / Auto |
|
|
Control System |
Live touch screen + remote PC |
|
|
Ignition method |
Remote ignition, integrated into the software interface |
|
|
Equipment structure |
Mobile console + open type |
|
|
Alarm function |
Foldable three-color lamp, abnormal operation alarm |
|
|
Protective function |
Upper and lower limit protection, foolproof function |
|
|
Equipment material |
Channel steel + cold rolled steel plate, painted, dark blue |
|
|
Ground bearing |
Requires solid ground, bearing 1T/m3 |
|
|
Power supply |
AC380V |
|
