Home > Products > Environmental Testing Machine > Solar Radiation Ozone Aging Test Chamber
Solar Radiation Ozone Aging Test Chamber
- 15 Set / Sets per Month
- Shenzhen
- T/T Credit Card
Product Details
Brand Name: | Haida | Place of Origin: | China | Model Number: | HD-E801 |
Power: | Electronic |
Product Description
Solar Radiation Ozone Aging Test Chamber
GENERL SPECIFICATIONS
Packaging Dimensions: (WxDxH) 1200*1200*1950mm
Power supply source: single-phase, 220V±10%, 50Hz (can be appointed)
Gross Weight: 280kg
HS Code: 8479899990
Standard Features
Model |
HD-E801 |
Internal dimension (WxDxH) |
500*600*500mm |
External dimension (WxDxH) |
1000*1000*1750mm |
Temperature range |
RT+10~ 60℃ (suggest to use 40℃±2℃) |
Temperature Fluctuation |
|
Humidity range |
30%~90%RH |
Humidity fluctuation |
±3%RH |
Ozone concentration |
50~1000 pphm, adjustable |
Ozone concentration deviation |
±10% |
Sample holder |
SUS#304 stainless steel |
Temperature controller |
Programmable touch screen controller |
Ozone concentration analysis |
Concentration analysis meter |
Ozone generator |
High pressure silence discharge type |
Protection system |
Leakage, short circuit, over temperature, over heat |
Test criteria |
ASTM D1149, ISO 1431, JIS K6259... |
Chamber Structure And Features
1, Internal material adopts high quality mirror stainless steel for ozone resistance.
2, Insulation material: high-density glass fiber
3, Use long axial fan motor and high and low temperature resistant aluminum alloy wing type wind turbines to force vertical air circulation.
4, Chamber door adopts double layer high and low temperature resistant silicone seal ensure the airtight test area.
5, Chamber bottom has high quality caster for convenient move.
6, Observation window uses multilayer hollow tempered glass.
7, Exhaust system: exhaust the high concentration ozone from the test chamber to avoid to poison.
8, Optional: Built-in 360 degree rotation sample holder, including 3 sets static tensile fixture and 3 sets dynamic tensile fixture.
